Switch unit steering column for BMW MINI Clubman F54 One (2019)
This Switch unit steering column technical drawing provides a detailed breakdown of the assembly for the MINI Clubman F54 One. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2019.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| For vehicles with Driving Assistant |
S5ASA=No |
|||||||||
| 02 | Switch unit steering column | 1 | 61316827362 | Shop at ECS Tuning | ||||||
| For vehicles with National version japan and Driving Assistant |
L807A=No S5ASA=Yes |
|||||||||
| 03 | Switch unit steering column | 1 | 61316827363 | Shop at ECS Tuning | ||||||
| 04 | Screw | KS-TS5X20-F-ZNS | 4 | 07129908720 | Shop at ECS Tuning | |||||
| 05 | Coil spring cartridge | 4B (ALP) | 1 | 61316992509 | Shop at ECS Tuning | |||||
See Also
Frequently Asked Questions
- What assembly is shown in the BMW MINI Clubman F54 One Switch unit steering column?
- This technical diagram illustrates the Switch unit steering column within the Vehicle electrical system group for the MINI Clubman F54 One produced during 2019. It provides a detailed exploded view of the components, identifying key parts such as the Switch unit steering column (Part #61316827362).
- Which models use the hardware listed in this Switch unit steering column?
- The hardware and components featured in the Switch unit steering column are specific to the MINI Clubman F54 One produced during 2019. These technical specifications ensure that parts like the Switch unit steering column (61316827362) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the Switch unit steering column assembly?
- Each item in the Switch unit steering column corresponds to the numbered list below the illustration. For the MINI Clubman F54 One, you can identify the Switch unit steering column by locating its position on the schematic, which then links to the official BMW part number 61316827362 for the Vehicle electrical system section.
