Horn for BMW 5 Series G30 LCI 520i (2020)
This Horn technical drawing provides a detailed breakdown of the assembly for the 5 Series G30 LCI 520i. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2020.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| For vehicles with National version japan and Hot-climate version |
L807A=No S823A=Yes |
|||||||||
| 01 | Fanfare horn high tone electronic | 1 | 61335A6AB59 | Shop at ECS Tuning | ||||||
| For vehicles with National version japan and Gulf version and National version China and Hot-climate version |
L807A=No L822A=No L8AAA=No S823A=No |
|||||||||
| 02 | Horn, low pitch | 1 | 61337342946 | Shop at ECS Tuning | ||||||
| For vehicles with Gulf version and National version China and Country version, India and Hot-climate version and Country-specific equipment Russia 10323 |
L822A=Yes L8AAA=Yes L8LAA=Yes S823A=Yes S8LRA=Yes |
|||||||||
| 02 | Fanfare horn low tone electronic | 1 | 61335A6AB60 | Shop at ECS Tuning | ||||||
