Relay separation 2nd battery K447 for BMW 5 Series G30 520i (2019)
This Relay separation 2nd battery K447 technical drawing provides a detailed breakdown of the assembly for the 5 Series G30 520i. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2019.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| i | For vehicles with Additional energy supply |
S146A=Yes |
||||||||
| 01 | Relay | 130A | 1 | 61369198302 | Shop at ECS Tuning | |||||
| 02 | Hex bolt with washer | M6X12-U1 | 2 | 07119904511 | $0.62 | Shop at ECS Tuning | ||||
| 03 | Hex nut with plate | M6-8-ZNNIV SI | 2 | 07119905544 | $0.64 | Shop at ECS Tuning | ||||
See Also
Frequently Asked Questions
- What assembly is shown in the BMW 5 Series G30 520i Relay separation 2nd battery K447?
- This technical diagram illustrates the Relay separation 2nd battery K447 within the Vehicle electrical system group for the 5 Series G30 520i produced during 2019. It provides a detailed exploded view of the components, identifying key parts such as the Relay (Part #61369198302).
- Which models use the hardware listed in this Relay separation 2nd battery K447?
- The hardware and components featured in the Relay separation 2nd battery K447 are specific to the 5 Series G30 520i produced during 2019. These technical specifications ensure that parts like the Relay (61369198302) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the Relay separation 2nd battery K447 assembly?
- Each item in the Relay separation 2nd battery K447 corresponds to the numbered list below the illustration. For the 5 Series G30 520i, you can identify the Relay by locating its position on the schematic, which then links to the official BMW part number 61369198302 for the Vehicle electrical system section.
