12-V lithium dual storage system for BMW 7 Series G11 LCI 730dX (2020)
This 12-V lithium dual storage system technical drawing provides a detailed breakdown of the assembly for the 7 Series G11 LCI 730dX. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2020.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | 12-V lithium dual storage system | 10AH | 1 | 03/2024 | 61215A4AF23 | Shop at ECS Tuning | ||||
| 01 | 12-V lithium dual storage system | 10AH | 1 | 11/2024 | 61215A8D7E0 | Shop at ECS Tuning | ||||
| 01 | Lithium dual storage system | 10AH | 1 | 61215B3F325 | Shop at ECS Tuning |
See Also
Frequently Asked Questions
- What assembly is shown in the BMW 7 Series G11 LCI 730dX 12-V lithium dual storage system?
- This technical diagram illustrates the 12-V lithium dual storage system within the Vehicle electrical system group for the 7 Series G11 LCI 730dX produced during 2020. It provides a detailed exploded view of the components, identifying key parts such as the 12-V lithium dual storage system (Part #61215A4AF23).
- Which models use the hardware listed in this 12-V lithium dual storage system?
- The hardware and components featured in the 12-V lithium dual storage system are specific to the 7 Series G11 LCI 730dX produced during 2020. These technical specifications ensure that parts like the 12-V lithium dual storage system (61215A4AF23) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the 12-V lithium dual storage system assembly?
- Each item in the 12-V lithium dual storage system corresponds to the numbered list below the illustration. For the 7 Series G11 LCI 730dX, you can identify the 12-V lithium dual storage system by locating its position on the schematic, which then links to the official BMW part number 61215A4AF23 for the Vehicle electrical system section.
