Single wiper parts for BMW MINI Cabrio F57 LCI One (2022)
This Single wiper parts technical drawing provides a detailed breakdown of the assembly for the MINI Cabrio F57 LCI One. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2022.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Wiper arm, driver's side | 1 | 61617376349 | Shop at ECS Tuning | ||||||
| 02 | Wiper arm, passenger's side | 1 | 61617335477 | Shop at ECS Tuning | ||||||
| 03 | Linkage for wiper system with motor | 1 | 61617419787 | Shop at ECS Tuning | ||||||
| 04 | Bracket | 1 | 61617315168 | Shop at ECS Tuning | ||||||
| 05 | Hex nut with plate | M6 | 1 | 07147311066 | Shop at ECS Tuning | |||||
| 06 | Hex bolt with washer | M6X30-U2-ZNS3 | 1 | 07119903994 | $0.65 | Shop at ECS Tuning | ||||
| 07 | Hex nut | 2 | 07146971889 | $0.82 | Shop at ECS Tuning | |||||
| 08 | Covering cap | 2 | 52108119867 | $0.21 | Shop at ECS Tuning |
See Also
Frequently Asked Questions
- What assembly is shown in the BMW MINI Cabrio F57 LCI One Single wiper parts?
- This technical diagram illustrates the Single wiper parts within the Vehicle electrical system group for the MINI Cabrio F57 LCI One produced during 2022. It provides a detailed exploded view of the components, identifying key parts such as the Wiper arm, driver's side (Part #61617376349).
- Which models use the hardware listed in this Single wiper parts?
- The hardware and components featured in the Single wiper parts are specific to the MINI Cabrio F57 LCI One produced during 2022. These technical specifications ensure that parts like the Wiper arm, driver's side (61617376349) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the Single wiper parts assembly?
- Each item in the Single wiper parts corresponds to the numbered list below the illustration. For the MINI Cabrio F57 LCI One, you can identify the Wiper arm, driver's side by locating its position on the schematic, which then links to the official BMW part number 61617376349 for the Vehicle electrical system section.
