Original BMW battery add-on parts for BMW 5 Series G60 Sedan 540dX (2025)
This Original BMW battery add-on parts technical drawing provides a detailed breakdown of the assembly for the 5 Series G60 Sedan 540dX. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2025.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Battery tray auxiliary battery | 1 | 61215A0C7C0 | Shop at ECS Tuning | ||||||
| 02 | Battery clamping rail | 1 | 61215A1ACA9 | Shop at ECS Tuning | ||||||
| 04 | Holder battery tray | 1 | 61215A299A6 | Shop at ECS Tuning | ||||||
| 05 | Compensation element | 1 | 61215A1D4E9 | Shop at ECS Tuning | ||||||
| 06 | ASA screw | M6X10 | 2 | 07129907296 | Shop at ECS Tuning | |||||
| 08 | Hex bolt | M8X20-PC-ZNS3 | 1 | 51649907859 | Shop at ECS Tuning | |||||
| 09 | Vent hose for battery | 1 | 61219434008 | Shop at ECS Tuning | ||||||
| 10 | External Torx socket | M6X25 8.8 ZNS3 | 1 | 07145A5BF54 | Shop at ECS Tuning | |||||
| 11 | Hex bolt | M12X50 | 1 | 07119904904 | $2.12 | Shop at ECS Tuning |
See Also
Frequently Asked Questions
- What assembly is shown in the BMW 5 Series G60 Sedan 540dX Original BMW battery add-on parts?
- This technical diagram illustrates the Original BMW battery add-on parts within the Vehicle electrical system group for the 5 Series G60 Sedan 540dX produced during 2025. It provides a detailed exploded view of the components, identifying key parts such as the Battery tray auxiliary battery (Part #61215A0C7C0).
- Which models use the hardware listed in this Original BMW battery add-on parts?
- The hardware and components featured in the Original BMW battery add-on parts are specific to the 5 Series G60 Sedan 540dX produced during 2025. These technical specifications ensure that parts like the Battery tray auxiliary battery (61215A0C7C0) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the Original BMW battery add-on parts assembly?
- Each item in the Original BMW battery add-on parts corresponds to the numbered list below the illustration. For the 5 Series G60 Sedan 540dX, you can identify the Battery tray auxiliary battery by locating its position on the schematic, which then links to the official BMW part number 61215A0C7C0 for the Vehicle electrical system section.
