Power dist./ B+ distributor front for BMW 5 Series G60 Sedan 520d (2025)
This Power dist./ B+ distributor front technical drawing provides a detailed breakdown of the assembly for the 5 Series G60 Sedan 520d. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2025.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Power distr.box B+ jump start terminal | 600W | 1 | 61145A09A43 | Shop at ECS Tuning | |||||
| 02 | Lid B+ terminal point | 1 | 61145A09A50 | Shop at ECS Tuning | ||||||
| 03 | Lid power distribution box B+ | 2 | 61145A09A51 | Shop at ECS Tuning | ||||||
| 04 | Screw | V-M8GFX35 | 2 | 07129908701 | Shop at ECS Tuning | |||||
| 05 | Power distribution box | 1 | 61145A039C3 | Shop at ECS Tuning | ||||||
| 06 | Power distribution box | 1 | 61145A039C4 | Shop at ECS Tuning | ||||||
| 07 | Holder power distribution box | 1 | 61145A1D5F7 | Shop at ECS Tuning | ||||||
| 08 | Plastic nut for coarse threaded pin | M6 | 3 | 16131176747 | $0.53 | Shop at ECS Tuning | ||||
| 09 | Holder Basic Central Platform BCP | 1 | 61135A1D5F6 | Shop at ECS Tuning | ||||||
| 10 | Cover Basic Central Platform BCP | 1 | 61135A1D609 | Shop at ECS Tuning | ||||||
| 11 | Sheet metal screw | 4,8X16 | 4 | 07119907237 | Shop at ECS Tuning |
