Head-up display for BMW 5 Series E60 530i (2007)
This Head-up display technical drawing provides a detailed breakdown of the assembly for the 5 Series E60 530i. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2007.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Head-up display | 1 | 62309190871 | $3036.60 | Shop at ECS Tuning | |||||
| 02 | Height adjustment, head-up display | 1 | 62306933193 | $16.26 | +core | Shop at ECS Tuning | ||||
| 03 | Oval-head screw with anti-rotation lock | M6X35-8.8-ZNS3 | 2 | 07129904259 | $2.51 | Shop at ECS Tuning | ||||
| 04 | Blind rivet nut with collar | M6 | 2 | 07147121926 | $1.82 | Shop at ECS Tuning | ||||
| 05 | Trim piece for head-up display | SCHWARZ | 1 | 62306934584 | $40.06 | Shop at ECS Tuning | ||||
| 05 | Trim piece for head-up display | BASALTGRAU | 1 | 62306934586 | $40.06 | Shop at ECS Tuning | ||||
| 06 | Seal Head-Up Display | 1 | 62306936221 | $26.57 | Shop at ECS Tuning | |||||
| 07 | Reinforcement plate, interior | 1 | 62306936871 | $5.64 | Shop at ECS Tuning | |||||
| 08 | Reinforcement plate, exterior | 1 | 62306936223 | $5.64 | Shop at ECS Tuning | |||||
| 09 | Hex nut | M4 | 4 | 07119903769 | $0.36 | Shop at ECS Tuning | ||||
| 10 | Washer | 9X4,3X0,8-200HV | 4 | 07119904205 | $0.07 | Shop at ECS Tuning | ||||
| 11 | Clip | 4 | 62304332403 | $2.08 | ENDED | Shop at ECS Tuning | ||||
| 12 | Socket housing | 12 POL. | 1 | 61138384550 | $0.77 | Shop at ECS Tuning | ||||
| only in conjunction with | ||||||||||
| -- | Terminal socket MQS ELA | 0.2-0.5 MM² SN | 12 | 61131393704 | $0.23 | Shop at ECS Tuning | ||||
| -- | Rep. kit for socket housing | 12+2 POL. | 1 | 61132471239 | Shop at ECS Tuning | |||||
| -- | Terminal socket MQS ELA | 0,5-0,75 MM² AG | 12 | 61136931880 | Shop at ECS Tuning | |||||
| -- | Envelope f optical waveguide | 2POL. /SCHWARZ | 1 | 61138387214 | $1.83 | Shop at ECS Tuning | ||||
Notes
- +core = plus core charge (possibility of a return of the old part)
- ENDED = the part has been discontinued (no longer available).
