Headlight for BMW 7 Series E38 730i (1996)
This Headlight technical drawing provides a detailed breakdown of the assembly for the 7 Series E38 730i. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1996.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Headlight left | 1 | 09/1998 | 63128352021 | $429.66 | Shop at ECS Tuning | ||||
| 01 | Headlight right | 1 | 09/1998 | 63128352022 | $429.66 | Shop at ECS Tuning | ||||
| For vehicles with Chrome Line exterieur |
S346A=Yes |
|||||||||
| 01 | Headlight left | 1 | 09/1998 | 63128372089 | Shop at ECS Tuning | |||||
| 01 | Headlight right | 1 | 09/1998 | 63128372090 | Shop at ECS Tuning | |||||
| For vehicles with Xenon Light |
S522A=Yes |
|||||||||
| 01 | Headlight xenon, left | 1 | 03/1997 | 63128352745 | $1344.78 | ENDED | Shop at ECS Tuning | |||
| 01 | Headlight xenon, right | 1 | 03/1997 | 63128352746 | $1344.78 | ENDED | Shop at ECS Tuning | |||
| For vehicles with Chrome Line exterieur and Xenon Light |
S346A=Yes S522A=Yes |
|||||||||
| 01 | Headlight xenon, left | 1 | 03/1997 | 63128372097 | ENDED | Shop at ECS Tuning | ||||
| 01 | Headlight xenon, right | 1 | 03/1997 | 63128372098 | ENDED | Shop at ECS Tuning | ||||
Notes
- ENDED = the part has been discontinued (no longer available).
