Additional turn indicator lamp for BMW 7 Series F02 LCI 760Li (2015)
This Additional turn indicator lamp technical drawing provides a detailed breakdown of the assembly for the 7 Series F02 LCI 760Li. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2015.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| For vehicles with Park Assistent |
S5DPA=No |
|||||||||
| 01 | Covering front left | 1 | 51137298869 | Shop at ECS Tuning | ||||||
| 01 | Covering front right | 1 | 51137298870 | Shop at ECS Tuning | ||||||
| 02 | Trim cover, auxiliary turn signal, left | V12 | 1 | 63137202183 | $15.90 | Shop at ECS Tuning | ||||
| 02 | Trim cover, auxiliary turn signal, right | V12 | 1 | 63137202184 | Shop at ECS Tuning | |||||
| 04 | Auxiliary turn signal, mirror, left | 1 | 63137308535 | Shop at ECS Tuning | ||||||
| 04 | Auxiliary turn signal, mirror, right | 1 | 63137308536 | Shop at ECS Tuning | ||||||
See Also
Frequently Asked Questions
- What assembly is shown in the BMW 7 Series F02 LCI 760Li Additional turn indicator lamp?
- This technical diagram illustrates the Additional turn indicator lamp within the Lighting group for the 7 Series F02 LCI 760Li produced during 2015. It provides a detailed exploded view of the components, identifying key parts such as the Covering front left (Part #51137298869).
- Which models use the hardware listed in this Additional turn indicator lamp?
- The hardware and components featured in the Additional turn indicator lamp are specific to the 7 Series F02 LCI 760Li produced during 2015. These technical specifications ensure that parts like the Covering front left (51137298869) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the Additional turn indicator lamp assembly?
- Each item in the Additional turn indicator lamp corresponds to the numbered list below the illustration. For the 7 Series F02 LCI 760Li, you can identify the Covering front left by locating its position on the schematic, which then links to the official BMW part number 51137298869 for the Lighting section.
