LED module/fiber-optic conductor/ECU for BMW 5 Series G30 LCI 520d (2023)
This LED module/fiber-optic conductor/ECU technical drawing provides a detailed breakdown of the assembly for the 5 Series G30 LCI 520d. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2023.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| For vehicles with Ambient interior lighting Center console storage compartment |
S4URA=Yes |
|||||||||
| 02 | Optical conductor | 1 | 63316824295 | Shop at ECS Tuning | ||||||
| 03 | LED module | VIOLETT | 4 | 63317941160 | ENDED | Shop at ECS Tuning | ||||
Notes
- ENDED = the part has been discontinued (no longer available).
