Reflector for BMW 4 Series G82 M4 Coupé M4 (2024)
This Reflector technical drawing provides a detailed breakdown of the assembly for the 4 Series G82 M4 Coupé M4. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2024.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 02 | Reflector, rear left | M | 1 | 63148081815 | Shop at ECS Tuning | |||||
| 02 | Reflector, rear right | M | 1 | 63148081816 | Shop at ECS Tuning |
See Also
Frequently Asked Questions
- What assembly is shown in the BMW 4 Series G82 M4 Coupé M4 Reflector?
- This technical diagram illustrates the Reflector within the Lighting group for the 4 Series G82 M4 Coupé M4 produced during 2024. It provides a detailed exploded view of the components, identifying key parts such as the Reflector, rear left (Part #63148081815).
- Which models use the hardware listed in this Reflector?
- The hardware and components featured in the Reflector are specific to the 4 Series G82 M4 Coupé M4 produced during 2024. These technical specifications ensure that parts like the Reflector, rear left (63148081815) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the Reflector assembly?
- Each item in the Reflector corresponds to the numbered list below the illustration. For the 4 Series G82 M4 Coupé M4, you can identify the Reflector, rear left by locating its position on the schematic, which then links to the official BMW part number 63148081815 for the Lighting section.
