Various lamps for BMW MINI Cabrio F57 JCW (2021)
This Various lamps technical drawing provides a detailed breakdown of the assembly for the MINI Cabrio F57 JCW. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2021.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| For vehicles with MINI Excitement Package |
S4V9A=Yes |
|||||||||
| 01 | Interior light, front | 1 | 63319357950 | ENDED | Shop at ECS Tuning | |||||
| 01 | Interior light | HIGH CABRIO | 1 | 63315A714C9 | Shop at ECS Tuning | |||||
| For vehicles with MINI Excitement Package |
S4V9A=No |
|||||||||
| 01 | Interior light, front | 1 | 63319357949 | Shop at ECS Tuning | ||||||
| 02 | Optical conductor, radio / IHKA controls | 1 | 63319304045 | Shop at ECS Tuning | ||||||
| For vehicles with MINI Excitement Package Door opener Door compartment lamp Exterior mirror |
S4V9A=Yes |
|||||||||
| 03 | LED module | LED RGB C | 2 | 63319263454 | Shop at ECS Tuning | |||||
| For vehicles with MINI Yours Interior Style Off-White and MINI Yours Interior Style dk. cottonwood and MINI Yours Interior Style Fibre All LED module Door trim panel Door opener Door compartment lamp Contour line door Radio / IHKA controls |
S4GSA=Yes S4GTA=Yes S4GUA=Yes |
|||||||||
| 03 | LED module | LED RGB C | 4 | 63319263454 | Shop at ECS Tuning | |||||
| For vehicles with MINI Yours Interior Style Off-White and MINI Yours Interior Style dk. cottonwood and MINI Yours Interior Style Fibre All LED module Door trim panel Door opener Door compartment lamp Contour line door Radio / IHKA controls |
S4GSA=Yes S4GTA=Yes S4GUA=No |
|||||||||
| 03 | LED module | LED RGB C | 4 | 63319263454 | Shop at ECS Tuning | |||||
| For vehicles with MINI Yours Interior Style Off-White and MINI Yours Interior Style dk. cottonwood and MINI Yours Interior Style Fibre All LED module Door trim panel Door opener Door compartment lamp Contour line door Radio / IHKA controls |
S4GSA=Yes S4GTA=No S4GUA=Yes |
|||||||||
| 03 | LED module | LED RGB C | 4 | 63319263454 | Shop at ECS Tuning | |||||
| For vehicles with MINI Yours Interior Style Off-White and MINI Yours Interior Style dk. cottonwood and MINI Yours Interior Style Fibre All LED module Door trim panel Door opener Door compartment lamp Contour line door Radio / IHKA controls |
S4GSA=Yes S4GTA=No S4GUA=No |
|||||||||
| 03 | LED module | LED RGB C | 4 | 63319263454 | Shop at ECS Tuning | |||||
| For vehicles with MINI Yours Interior Style Off-White and MINI Yours Interior Style dk. cottonwood and MINI Yours Interior Style Fibre All LED module Door trim panel Door opener Door compartment lamp Contour line door Radio / IHKA controls |
S4GSA=No S4GTA=Yes S4GUA=Yes |
|||||||||
| 03 | LED module | LED RGB C | 4 | 63319263454 | Shop at ECS Tuning | |||||
| For vehicles with MINI Yours Interior Style Off-White and MINI Yours Interior Style dk. cottonwood and MINI Yours Interior Style Fibre All LED module Door trim panel Door opener Door compartment lamp Contour line door Radio / IHKA controls |
S4GSA=No S4GTA=Yes S4GUA=No |
|||||||||
| 03 | LED module | LED RGB C | 4 | 63319263454 | Shop at ECS Tuning | |||||
| For vehicles with MINI Yours Interior Style Off-White and MINI Yours Interior Style dk. cottonwood and MINI Yours Interior Style Fibre All LED module Door trim panel Door opener Door compartment lamp Contour line door Radio / IHKA controls |
S4GSA=No S4GTA=No S4GUA=Yes |
|||||||||
| 03 | LED module | LED RGB C | 4 | 63319263454 | Shop at ECS Tuning | |||||
| Centre console | ||||||||||
| 04 | LED module | LED RGB C | 1 | 63319263454 | Shop at ECS Tuning | |||||
| 04 | LED module | ORANGE | 2 | 63319343149 | Shop at ECS Tuning | |||||
| For vehicles with MINI Excitement Package Footwell lamp |
S4V9A=Yes |
|||||||||
| 04 | LED for interior lamp | AMBIENTE RGB | 2 | 63319263453 | Shop at ECS Tuning | |||||
| For vehicles with MINI Yours Interior Style Piano Black Instrument cluster |
S4GVA=Yes |
|||||||||
| 04 | LED module | LED RGB C | 3 | 63319263454 | Shop at ECS Tuning | |||||
| For vehicles with MINI Excitement Package Footwell lamp |
S4V9A=No |
|||||||||
| 04 | LED for interior lamp | HIGH POWER | 2 | 63317941911 | Shop at ECS Tuning | |||||
| Door courtesy lamp | ||||||||||
| 05 | LED for interior lamp | KALTWEISS | 1 | 63319313574 | Shop at ECS Tuning | |||||
| For vehicles with MINI Excitement Package Door courtesy lamp |
S4V9A=Yes |
|||||||||
| 05 | LED for interior lamp | KALTWEISS | 2 | 63319313574 | Shop at ECS Tuning | |||||
| For vehicles with MINI Excitement Package |
S4V9A=Yes |
|||||||||
| 06 | Light guide, door trim panel, left | 1 | 63319304047 | Shop at ECS Tuning | ||||||
| 06 | Light guide, door trim panel, right | 1 | 63319304048 | Shop at ECS Tuning | ||||||
| 07 | Optical conductor, door opener | 2 | 63319304049 | Shop at ECS Tuning | ||||||
| GLOVE BOX | ||||||||||
| 09 | Interior light | 5W TRÜB | 1 | 63316972605 | $11.92 | Shop at ECS Tuning | ||||
| Luggage compartment light | ||||||||||
| 11 | LED for interior lamp | KALTWEISS | 1 | 63319313574 | Shop at ECS Tuning | |||||
| For vehicles with MINI Yours interior style burgundy and MINI Yours Interior Style Fibre All and MINI Excitement Package and Light package |
S4GWA=Yes S4GXA=Yes S4V9A=Yes S563A=Yes |
|||||||||
| 12 | LED module | LED RGB C | 2 | 63319263454 | Shop at ECS Tuning | |||||
| For vehicles with MINI Yours interior style burgundy and MINI Yours Interior Style Fibre All and MINI Excitement Package and Light package |
S4GWA=Yes S4GXA=Yes S4V9A=Yes S563A=No |
|||||||||
| 12 | LED module | LED RGB C | 2 | 63319263454 | Shop at ECS Tuning | |||||
| For vehicles with MINI Yours interior style burgundy and MINI Yours Interior Style Fibre All and MINI Excitement Package and Light package |
S4GWA=Yes S4GXA=Yes S4V9A=No S563A=Yes |
|||||||||
| 12 | LED module | LED RGB C | 2 | 63319263454 | Shop at ECS Tuning | |||||
| For vehicles with MINI Yours interior style burgundy and MINI Yours Interior Style Fibre All and MINI Excitement Package and Light package |
S4GWA=Yes S4GXA=Yes S4V9A=No S563A=No |
|||||||||
| 12 | LED module | LED RGB C | 2 | 63319263454 | Shop at ECS Tuning | |||||
| For vehicles with MINI Yours interior style burgundy and MINI Yours Interior Style Fibre All and MINI Excitement Package and Light package |
S4GWA=Yes S4GXA=No S4V9A=Yes S563A=Yes |
|||||||||
| 12 | LED module | LED RGB C | 2 | 63319263454 | Shop at ECS Tuning | |||||
| For vehicles with MINI Yours interior style burgundy and MINI Yours Interior Style Fibre All and MINI Excitement Package and Light package |
S4GWA=Yes S4GXA=No S4V9A=Yes S563A=No |
|||||||||
| 12 | LED module | LED RGB C | 2 | 63319263454 | Shop at ECS Tuning | |||||
| For vehicles with MINI Yours interior style burgundy and MINI Yours Interior Style Fibre All and MINI Excitement Package and Light package |
S4GWA=Yes S4GXA=No S4V9A=No S563A=Yes |
|||||||||
| 12 | LED module | LED RGB C | 2 | 63319263454 | Shop at ECS Tuning | |||||
| For vehicles with MINI Yours interior style burgundy and MINI Yours Interior Style Fibre All and MINI Excitement Package and Light package |
S4GWA=Yes S4GXA=No S4V9A=No S563A=No |
|||||||||
| 12 | LED module | LED RGB C | 2 | 63319263454 | Shop at ECS Tuning | |||||
| For vehicles with MINI Yours interior style burgundy and MINI Yours Interior Style Fibre All and MINI Excitement Package and Light package |
S4GWA=No S4GXA=Yes S4V9A=Yes S563A=Yes |
|||||||||
| 12 | LED module | LED RGB C | 2 | 63319263454 | Shop at ECS Tuning | |||||
| For vehicles with MINI Yours interior style burgundy and MINI Yours Interior Style Fibre All and MINI Excitement Package and Light package |
S4GWA=No S4GXA=Yes S4V9A=Yes S563A=No |
|||||||||
| 12 | LED module | LED RGB C | 2 | 63319263454 | Shop at ECS Tuning | |||||
| For vehicles with MINI Yours interior style burgundy and MINI Yours Interior Style Fibre All and MINI Excitement Package and Light package |
S4GWA=No S4GXA=Yes S4V9A=No S563A=Yes |
|||||||||
| 12 | LED module | LED RGB C | 2 | 63319263454 | Shop at ECS Tuning | |||||
| For vehicles with MINI Yours interior style burgundy and MINI Yours Interior Style Fibre All and MINI Excitement Package and Light package |
S4GWA=No S4GXA=Yes S4V9A=No S563A=No |
|||||||||
| 12 | LED module | LED RGB C | 2 | 63319263454 | Shop at ECS Tuning | |||||
| For vehicles with MINI Yours interior style burgundy and MINI Yours Interior Style Fibre All and MINI Excitement Package and Light package |
S4GWA=No S4GXA=No S4V9A=Yes S563A=Yes |
|||||||||
| 12 | LED module | LED RGB C | 2 | 63319263454 | Shop at ECS Tuning | |||||
| For vehicles with MINI Yours interior style burgundy and MINI Yours Interior Style Fibre All and MINI Excitement Package and Light package |
S4GWA=No S4GXA=No S4V9A=Yes S563A=No |
|||||||||
| 12 | LED module | LED RGB C | 2 | 63319263454 | Shop at ECS Tuning | |||||
| For vehicles with MINI Yours interior style burgundy and MINI Yours Interior Style Fibre All and MINI Excitement Package and Light package |
S4GWA=No S4GXA=No S4V9A=No S563A=Yes |
|||||||||
| 12 | LED module | LED RGB C | 2 | 63319263454 | Shop at ECS Tuning | |||||
Notes
- ENDED = the part has been discontinued (no longer available).
