Fiber-optic conductor, vehicle interior for BMW 4 Series G26 Gran Coupé LCI 430i (2025)
This Fiber-optic conductor, vehicle interior technical drawing provides a detailed breakdown of the assembly for the 4 Series G26 Gran Coupé LCI 430i. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2025.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | LED module | SCHWARZ | 1 | 63319475836 | Shop at ECS Tuning | |||||
| 02 | LED module | LIN H-RGB KOD.B | 1 | 63315A5CB60 | Shop at ECS Tuning | |||||
| 03 | LED module | RGB H KOD.B2 | 1 | 63315A76320 | Shop at ECS Tuning | |||||
| 03 | LED module | RGB H KOD D1 | 1 | 63315A76321 | Shop at ECS Tuning | |||||
| 04 | LED module | LIN H-RGB KOD.B | 8 | 63315A5CB60 | Shop at ECS Tuning | |||||
| 05 | LED module | VIOLETT | 2 | 63315A5CB61 | Shop at ECS Tuning |
See Also
Frequently Asked Questions
- What assembly is shown in the BMW 4 Series G26 Gran Coupé LCI 430i Fiber-optic conductor, vehicle interior?
- This technical diagram illustrates the Fiber-optic conductor, vehicle interior within the Lighting group for the 4 Series G26 Gran Coupé LCI 430i produced during 2025. It provides a detailed exploded view of the components, identifying key parts such as the LED module (Part #63319475836).
- Which models use the hardware listed in this Fiber-optic conductor, vehicle interior?
- The hardware and components featured in the Fiber-optic conductor, vehicle interior are specific to the 4 Series G26 Gran Coupé LCI 430i produced during 2025. These technical specifications ensure that parts like the LED module (63319475836) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the Fiber-optic conductor, vehicle interior assembly?
- Each item in the Fiber-optic conductor, vehicle interior corresponds to the numbered list below the illustration. For the 4 Series G26 Gran Coupé LCI 430i, you can identify the LED module by locating its position on the schematic, which then links to the official BMW part number 63319475836 for the Lighting section.
