Switch air conditioning for BMW 5 Series E12 520i (1976)
This Switch air conditioning technical drawing provides a detailed breakdown of the assembly for the 5 Series E12 520i. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1976.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Cover | 1 | 02/1977 | 51161849597 | ENDED | Shop at ECS Tuning | ||||
| 02 | Knob temperature | 1 | 02/1977 | 64511356021 | ENDED | Shop at ECS Tuning | ||||
| 03 | Ring nut | 1 | 02/1977 | 64511352089 | $2.06 | ENDED | Shop at ECS Tuning | |||
| 04 | Knob temperature | 1 | 02/1977 | 64511356022 | $48.82 | ENDED | Shop at ECS Tuning | |||
| 05 | Ring nut | 1 | 02/1977 | 65111351267 | ENDED | Shop at ECS Tuning | ||||
| 06 | Cover | 1 | 02/1977 | 51161817966 | ENDED | Shop at ECS Tuning | ||||
| 07 | Gear lever cover | 1 | 10/1975 | 02/1977 | 51161849569 | ENDED | Shop at ECS Tuning | |||
| 08 | Label "air condition" | 1275G | 1 | 02/1977 | 64501380984 | $6.67 | ENDED | Shop at ECS Tuning |
Notes
- ENDED = the part has been discontinued (no longer available).
See Also
Frequently Asked Questions
- What assembly is shown in the BMW 5 Series E12 520i Switch air conditioning?
- This technical diagram illustrates the Switch air conditioning within the Heater and Air Conditioning group for the 5 Series E12 520i produced during 1976. It provides a detailed exploded view of the components, identifying key parts such as the Cover (Part #51161849597).
- Which models use the hardware listed in this Switch air conditioning?
- The hardware and components featured in the Switch air conditioning are specific to the 5 Series E12 520i produced during 1976. These technical specifications ensure that parts like the Cover (51161849597) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the Switch air conditioning assembly?
- Each item in the Switch air conditioning corresponds to the numbered list below the illustration. For the 5 Series E12 520i, you can identify the Cover by locating its position on the schematic, which then links to the official BMW part number 51161849597 for the Heater and Air Conditioning section.
