Air conditioning unit parts for BMW 2.5CS-3.0CSL 3.0CSL (1973)
This Air conditioning unit parts technical drawing provides a detailed breakdown of the assembly for the 2.5CS-3.0CSL 3.0CSL. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1973.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| For vehicles with Air conditioning |
=Yes |
|||||||||
| 01 | Storing partition | 1 | 09/1971 | 11/1975 | 51161826885 | ENDED | Shop at ECS Tuning | |||
| 02 | Body nut | ST4,2-2ZNS | 2 | 07129901645 | $0.11 | Shop at ECS Tuning | ||||
| 03 | Bracket | 1 | 51161811461 | ENDED | Shop at ECS Tuning | |||||
| 04 | Hollow washer | 2 | 51211859979 | $0.40 | Shop at ECS Tuning | |||||
| 05 | Recessed oval head sheet-metal screw | ST4,2X32 | 2 | 07119902475 | $0.09 | ENDED | Shop at ECS Tuning | |||
| 06 | Countersunk head screw | M5X15 | 2 | 07119900717 | ENDED | Shop at ECS Tuning | ||||
| 07 | BMW Classic | 0000000000 | 2 | 07119936115 | ENDED | Shop at ECS Tuning | ||||
| 08 | Bracket | 1 | 51161811459 | ENDED | Shop at ECS Tuning | |||||
| 08 | Bracket | 1 | 51161811460 | ENDED | Shop at ECS Tuning | |||||
Notes
- ENDED = the part has been discontinued (no longer available).
See Also
Frequently Asked Questions
- What assembly is shown in the BMW 2.5CS-3.0CSL 3.0CSL Air conditioning unit parts?
- This technical diagram illustrates the Air conditioning unit parts within the Heater and Air Conditioning group for the 2.5CS-3.0CSL 3.0CSL produced during 1973. It provides a detailed exploded view of the components, identifying key parts such as the Storing partition (Part #51161826885).
- Which models use the hardware listed in this Air conditioning unit parts?
- The hardware and components featured in the Air conditioning unit parts are specific to the 2.5CS-3.0CSL 3.0CSL produced during 1973. These technical specifications ensure that parts like the Storing partition (51161826885) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the Air conditioning unit parts assembly?
- Each item in the Air conditioning unit parts corresponds to the numbered list below the illustration. For the 2.5CS-3.0CSL 3.0CSL, you can identify the Storing partition by locating its position on the schematic, which then links to the official BMW part number 51161826885 for the Heater and Air Conditioning section.
