Radio for BMW 3 Series E30 325ix (1991)
This Radio technical drawing provides a detailed breakdown of the assembly for the 3 Series E30 325ix. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1991.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Frame | 1 | 65121375737 | $13.10 | Shop at ECS Tuning | |||||
| 02 | Wiring set | BAV.ELECTR.CD | 1 | 65121386624 | ENDED | Shop at ECS Tuning | ||||
| 03 | Antenna adapter tubing | 1 | 65121388950 | $14.22 | Shop at ECS Tuning | |||||
| 04 | Support | 1 | 16121150544 | Shop at ECS Tuning | ||||||
| 05 | Holder | 1 | 65121388951 | ENDED | Shop at ECS Tuning | |||||
| 06 | Washer | 6-200 HV-ZNS3 | 2 | 07119904606 | $0.84 | Shop at ECS Tuning | ||||
| 07 | Hex bolt | M6X8 | 3 | 07119913420 | $0.13 | ENDED | Shop at ECS Tuning | |||
| 08 | Adapter lead | HIFI/4-KANAL | 1 | 61101388934 | $36.85 | ENDED | Shop at ECS Tuning | |||
| 09 | Adapter lead | 1 | 65111372723 | $9.93 | ENDED | Shop at ECS Tuning |
Notes
- ENDED = the part has been discontinued (no longer available).
See Also
Frequently Asked Questions
- What assembly is shown in the BMW 3 Series E30 325ix Radio?
- This technical diagram illustrates the Radio within the Audio, Navigation, Electronic Systems group for the 3 Series E30 325ix produced during 1991. It provides a detailed exploded view of the components, identifying key parts such as the Frame (Part #65121375737).
- Which models use the hardware listed in this Radio?
- The hardware and components featured in the Radio are specific to the 3 Series E30 325ix produced during 1991. These technical specifications ensure that parts like the Frame (65121375737) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the Radio assembly?
- Each item in the Radio corresponds to the numbered list below the illustration. For the 3 Series E30 325ix, you can identify the Frame by locating its position on the schematic, which then links to the official BMW part number 65121375737 for the Audio, Navigation, Electronic Systems section.
