Antenna accessories for BMW 3 Series E30 318i (1994)
This Antenna accessories technical drawing provides a detailed breakdown of the assembly for the 3 Series E30 318i. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1994.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Installing set roof antenna | 1 | 65224191630 | $77.22 | Shop at ECS Tuning | |||||
| 02 | Antenna | 1 | 65221386412 | $34.19 | Shop at ECS Tuning | |||||
| 03 | Cover | 1 | 65221386413 | $1.13 | ENDED | Shop at ECS Tuning | ||||
| 04 | Cable holder | X | 61131381722 | $6.98 | ENDED | Shop at ECS Tuning | ||||
| 05 | Antenna adapter tubing | 1 | 09/1989 | 65121388950 | $14.22 | Shop at ECS Tuning |
Notes
- ENDED = the part has been discontinued (no longer available).
See Also
Frequently Asked Questions
- What assembly is shown in the BMW 3 Series E30 318i Antenna accessories?
- This technical diagram illustrates the Antenna accessories within the Audio, Navigation, Electronic Systems group for the 3 Series E30 318i produced during 1994. It provides a detailed exploded view of the components, identifying key parts such as the Installing set roof antenna (Part #65224191630).
- Which models use the hardware listed in this Antenna accessories?
- The hardware and components featured in the Antenna accessories are specific to the 3 Series E30 318i produced during 1994. These technical specifications ensure that parts like the Installing set roof antenna (65224191630) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the Antenna accessories assembly?
- Each item in the Antenna accessories corresponds to the numbered list below the illustration. For the 3 Series E30 318i, you can identify the Installing set roof antenna by locating its position on the schematic, which then links to the official BMW part number 65224191630 for the Audio, Navigation, Electronic Systems section.
