Single parts f package shelf hifi system for BMW 7 Series F02 LCI 740Li (2015)
This Single parts f package shelf hifi system technical drawing provides a detailed breakdown of the assembly for the 7 Series F02 LCI 740Li. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2015.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | HiFi loudspeaker carrier, left | HIFI-SYSTEM | 1 | 65139151969 | Shop at ECS Tuning | |||||
| 01 | HiFi loudspeaker carrier, right | HIFI-SYSTEM | 1 | 65139151970 | Shop at ECS Tuning | |||||
| 02 | mid-range loudspeaker hifi | 2 | 65139240641 | Shop at ECS Tuning | ||||||
| 03 | Hex nut | M5-8-ZNFE SW | 6 | 07119903790 | $0.25 | Shop at ECS Tuning | ||||
| 04 | Hifi-System Tweeter | 2 | 65139212077 | Shop at ECS Tuning | ||||||
| 05 | Hex head screw | ST4,8X19-U2 SW | 8 | 07119904288 | $2.05 | Shop at ECS Tuning |
See Also
Frequently Asked Questions
- What assembly is shown in the BMW 7 Series F02 LCI 740Li Single parts f package shelf hifi system?
- This technical diagram illustrates the Single parts f package shelf hifi system within the Audio, Navigation, Electronic Systems group for the 7 Series F02 LCI 740Li produced during 2015. It provides a detailed exploded view of the components, identifying key parts such as the HiFi loudspeaker carrier, left (Part #65139151969).
- Which models use the hardware listed in this Single parts f package shelf hifi system?
- The hardware and components featured in the Single parts f package shelf hifi system are specific to the 7 Series F02 LCI 740Li produced during 2015. These technical specifications ensure that parts like the HiFi loudspeaker carrier, left (65139151969) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the Single parts f package shelf hifi system assembly?
- Each item in the Single parts f package shelf hifi system corresponds to the numbered list below the illustration. For the 7 Series F02 LCI 740Li, you can identify the HiFi loudspeaker carrier, left by locating its position on the schematic, which then links to the official BMW part number 65139151969 for the Audio, Navigation, Electronic Systems section.
