Sep.CMPT High End Sound Syst. door front for BMW 8 Series G14 Convertible M850iX (2025)
This Sep.CMPT High End Sound Syst. door front technical drawing provides a detailed breakdown of the assembly for the 8 Series G14 Convertible M850iX. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2025.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| i | For vehicles with Bowers & Wilkins High End Sound System |
S6F1A=Yes |
||||||||
| 01 | Tweeter | ALEV 4 | 2 | 65139350327 | Shop at ECS Tuning | |||||
| 02 | MID-range loudspeaker | HIGH END | 2 | 65139279635 | Shop at ECS Tuning | |||||
| 03 | Fiber-optic cable, left | 1 | 65139871959 | Shop at ECS Tuning | ||||||
| 03 | Fiber-optic cable, right | 1 | 65139871960 | Shop at ECS Tuning | ||||||
| 04 | Retaining ring, left | 1 | 65139871942 | Shop at ECS Tuning | ||||||
| 04 | Retaining ring, right | 1 | 65139872660 | Shop at ECS Tuning | ||||||
| 05 | Fillister head screw | TS 5X16 | 6 | 51417067920 | $0.39 | Shop at ECS Tuning | ||||
| 06 | Expanding nut | 7X7 MM | 6 | 65138387414 | $0.47 | Shop at ECS Tuning | ||||
See Also
Frequently Asked Questions
- What assembly is shown in the BMW 8 Series G14 Convertible M850iX Sep.CMPT High End Sound Syst. door front?
- This technical diagram illustrates the Sep.CMPT High End Sound Syst. door front within the Audio, Navigation, Electronic Systems group for the 8 Series G14 Convertible M850iX produced during 2025. It provides a detailed exploded view of the components, identifying key parts such as the Tweeter (Part #65139350327).
- Which models use the hardware listed in this Sep.CMPT High End Sound Syst. door front?
- The hardware and components featured in the Sep.CMPT High End Sound Syst. door front are specific to the 8 Series G14 Convertible M850iX produced during 2025. These technical specifications ensure that parts like the Tweeter (65139350327) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the Sep.CMPT High End Sound Syst. door front assembly?
- Each item in the Sep.CMPT High End Sound Syst. door front corresponds to the numbered list below the illustration. For the 8 Series G14 Convertible M850iX, you can identify the Tweeter by locating its position on the schematic, which then links to the official BMW part number 65139350327 for the Audio, Navigation, Electronic Systems section.
