Receiver Audio Module for BMW 3 Series G20 Sedan LCI M340dX (2025)
This Receiver Audio Module technical drawing provides a detailed breakdown of the assembly for the 3 Series G20 Sedan LCI M340dX. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2025.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| For vehicles with DAB tuner and Harman/Kardon Surround Sound system |
S654A=No S688A=No |
|||||||||
| 01 | RP RAM | MID HP R | 1 | 65125B44D49 | Shop at ECS Tuning | |||||
| For vehicles with DAB tuner and Harman/Kardon Surround Sound system |
S654A=Yes S688A=No |
|||||||||
| 01 | RP RAM | MID DAB | 1 | 65125B44D47 | Shop at ECS Tuning | |||||
| For vehicles with DAB tuner and Harman/Kardon Surround Sound system |
S654A=No S688A=Yes |
|||||||||
| 01 | RP RAM | HIGH ECO R | 1 | 65125B44D34 | Shop at ECS Tuning | |||||
| For vehicles with DAB tuner and Harman/Kardon Surround Sound system |
S654A=Yes S688A=Yes |
|||||||||
| 01 | RP RAM | DAB HIGH ECO | 1 | 65125B44D33 | Shop at ECS Tuning | |||||
| 02 | Bracket RAM/ICAM | 1 | 65159865515 | Shop at ECS Tuning | ||||||
| 03 | Hex nut | M5 | 3 | 07119905710 | $2.83 | Shop at ECS Tuning | ||||
| 04 | Hex nut | BM6-8-ZNNIV SI | 1 | 07129905411 | $0.38 | Shop at ECS Tuning | ||||
See Also
Frequently Asked Questions
- What assembly is shown in the BMW 3 Series G20 Sedan LCI M340dX Receiver Audio Module?
- This technical diagram illustrates the Receiver Audio Module within the Audio, Navigation, Electronic Systems group for the 3 Series G20 Sedan LCI M340dX produced during 2025. It provides a detailed exploded view of the components, identifying key parts such as the RP RAM (Part #65125B44D49).
- Which models use the hardware listed in this Receiver Audio Module?
- The hardware and components featured in the Receiver Audio Module are specific to the 3 Series G20 Sedan LCI M340dX produced during 2025. These technical specifications ensure that parts like the RP RAM (65125B44D49) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the Receiver Audio Module assembly?
- Each item in the Receiver Audio Module corresponds to the numbered list below the illustration. For the 3 Series G20 Sedan LCI M340dX, you can identify the RP RAM by locating its position on the schematic, which then links to the official BMW part number 65125B44D49 for the Audio, Navigation, Electronic Systems section.
