Park Distance Control (PDC) for BMW MINI Clubman F54 Cooper (2019)
This Park Distance Control (PDC) technical drawing provides a detailed breakdown of the assembly for the MINI Clubman F54 Cooper. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2019.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| For vehicles with Park Assistent |
S5DPA=Yes |
|||||||||
| 01 | Control module for Park Assistant | PMA-VA01 | 1 | 66335A02F94 | Shop at ECS Tuning | |||||
| For vehicles with Park Distance Control (PDC), rear and Park Assistent |
S507A=Yes S5DPA=No |
|||||||||
| 01 | Control unit PDC | PDC-VA01 | 1 | 66335A02F95 | Shop at ECS Tuning | |||||
| 02 | Ultrasonic sensor, black | 5.7.1 AXIAL | 2 | 66209274428 | Shop at ECS Tuning | |||||
| 03 | Ultrasonic sensor, black | 5.7.1 RADIAL | 4 | 66209274427 | Shop at ECS Tuning | |||||
| 04 | Ultrasonic sensor, color code | 2 | 66202409651 | Shop at ECS Tuning | ||||||
| Control number for individual colors Attention, important info for vehicles with individual painting: After entering the vehicle identification number in "Vehicle details", select the "Equipment" option. For vehicles with individual painting, the key number must be searched for/selected manually in the condition evaluation, which allows the sensor to appear in the correct color. If the key number cannot be found in the list, the sensor color code must be ordered with the appropriate key number. |
||||||||||
| For vehicles with thunder-grey metallic |
WB58=Yes |
|||||||||
| 04 | Ultrasonic sensor, Thunder Gray | WB58 | 2 | 66209302469 | Shop at ECS Tuning | |||||
| For vehicles with rebel-green |
YC19=Yes |
|||||||||
| 04 | Ultrasonic sensor, Rebel Green | YC19 | 2 | 66209336924 | Shop at ECS Tuning | |||||
| For vehicles with British Racing green iv metallic |
WC3B=Yes |
|||||||||
| 04 | Ultrasonic sensor, British-Racing Green | WC3B | 2 | 66209490145 | Shop at ECS Tuning | |||||
| For vehicles with iced-chocolate metallic |
WB49=Yes |
|||||||||
| 04 | Ultrasonic sensor, Iced Chocolate | WB49 | 2 | 66209302468 | Shop at ECS Tuning | |||||
| For vehicles with starlight-blue metallic |
WB62=Yes |
|||||||||
| 04 | Ultrasonic sensor, Starlight Blue | WB62 | 2 | 66206823118 | Shop at ECS Tuning | |||||
| For vehicles with british-racing-green metallic |
WB22=Yes |
|||||||||
| 04 | Ultrasonic sensor, British-Racing Green | WB22 | 2 | 66209302471 | Shop at ECS Tuning | |||||
| For vehicles with Nanuq White |
WC6A=Yes |
|||||||||
| 04 | Ultrasonic sensor Nanuq White | WC6A | 2 | 66205A35589 | Shop at ECS Tuning | |||||
| For vehicles with lapisluxury-blue |
YC24=Yes |
|||||||||
| 04 | Ultrasonic sensor, Lapisluxury Blue met. | YC24 | 2 | 66209348911 | Shop at ECS Tuning | |||||
| For vehicles with digital-blue metallic |
WC2B=Yes |
|||||||||
| 04 | Ultrasonic sensor, Digital blue metallic | WC2B | 2 | 66209359589 | Shop at ECS Tuning | |||||
| For vehicles with pure-burgundy metallic |
WC2C=Yes |
|||||||||
| 04 | Ultrasonic sensor, Pure Burgundy met. | WC2C | 2 | 66209359604 | Shop at ECS Tuning | |||||
| For vehicles with white-silver metallic |
WA62=Yes |
|||||||||
| 04 | Ultrasonic sensor, White Silver | WA62 | 2 | 66209302472 | Shop at ECS Tuning | |||||
| For vehicles with chili-red |
U851=Yes |
|||||||||
| 04 | Ultrasonic sensor, Chili Red | U851 | 2 | 66209302550 | Shop at ECS Tuning | |||||
| For vehicles with Melting Silver III |
WC6B=Yes |
|||||||||
| 04 | Ultrasonic sensor Melting Silver III | WC6B | 2 | 66205A35594 | Shop at ECS Tuning | |||||
| For vehicles with alpinweiss 3 |
U300=Yes |
|||||||||
| 04 | Ultrasonic sensor, Alpine White | U300 | 2 | 66209283751 | Shop at ECS Tuning | |||||
| For vehicles with estoril-blau metallic |
WB45=Yes |
|||||||||
| 04 | Ultrasonic sensor, Estoril Blue | WB45 | 2 | 66209336909 | Shop at ECS Tuning | |||||
| For vehicles with platin-silber metallic |
WC08=Yes |
|||||||||
| 04 | Ultrasonic sensor, Platinum Silver | WC08 WC2U | 2 | 66209336912 | Shop at ECS Tuning | |||||
| For vehicles with mineral-grau metallic |
WB39=Yes |
|||||||||
| 04 | Ultrasonic sensor, Mineral Gray | WB39 WC2V | 2 | 66209336906 | Shop at ECS Tuning | |||||
| For vehicles with volcanic-orange |
YB70=Yes |
|||||||||
| 04 | Ultrasonic sensor, Volcanic Orange | YB70 | 2 | 66209302549 | Shop at ECS Tuning | |||||
| For vehicles with deep-blue metallic |
WB69=Yes |
|||||||||
| 04 | Ultrasonic sensor, Deep Blue | WB69 | 2 | 66209302473 | Shop at ECS Tuning | |||||
| For vehicles with Indian red metallic |
WC3X=Yes |
|||||||||
| 04 | Ultrasonic sensor, Indian Red | WC3X | 2 | 66209461168 | Shop at ECS Tuning | |||||
| For vehicles with Enigmatic black metallic |
WC3Y=Yes |
|||||||||
| 04 | Ultrasonic sensor, Enigmatic Black | WC3Y | 2 | 66209475029 | Shop at ECS Tuning | |||||
| For vehicles with electric-blue metallic |
WB86=Yes |
|||||||||
| 04 | Ultrasonic sensor, Electric Blue met. | WB86 | 2 | 66209336921 | Shop at ECS Tuning | |||||
| For vehicles with moonwalk-grey metallic |
WB71=Yes |
|||||||||
| 04 | Ultrasonic sensor, Moonwalk Gray | WB71 | 2 | 66209302467 | Shop at ECS Tuning | |||||
| For vehicles with midnight-black metallic |
WA94=Yes |
|||||||||
| 04 | Ultrasonic sensor, Midnight Black | WA94 | 2 | 66209302470 | Shop at ECS Tuning | |||||
| For vehicles with blazing-red metallic |
WB83=Yes |
|||||||||
| 04 | Ultrasonic sensor, Blazing Red 2 | WB83 | 2 | 66209302466 | Shop at ECS Tuning | |||||
| For vehicles with pepper-white |
U850=Yes |
|||||||||
| 04 | Ultrasonic sensor, Pepper White | U850 | 2 | 66209302548 | Shop at ECS Tuning | |||||
| For vehicles with atlantik-grau metallic |
WC09=Yes |
|||||||||
| 04 | Ultrasonic sensor, Atlantic Gray | WC09 | 2 | 66209336915 | Shop at ECS Tuning | |||||
| For vehicles with mediterran-blau metallic |
WC10=Yes |
|||||||||
| 04 | Ultrasonic sensor, Mediterranean Blue | WC10 | 2 | 66209336918 | Shop at ECS Tuning | |||||
| For vehicles with melting-silver metallic |
WC2K=Yes |
|||||||||
| 04 | Ultrasonic sensor, Melting Silver met. | WC2K | 2 | 66209359607 | Shop at ECS Tuning | |||||
| For vehicles with carbon-schwarz or black-sapphire metallic or black 2 or without application or without application or midnight-black metallic or azurit-metallic black or rubin-metallic black |
M416=Yes M475=Yes U668=Yes U973=Yes U974=Yes WA94=Yes WS34=Yes WX03=Yes |
|||||||||
| 04 | Ultrasonic sensor, black | 5.7.1 AXIAL | 2 | 66209274428 | Shop at ECS Tuning | |||||
| 05 | Decoupling ring PDC torque converter | 8 | 66209283203 | Shop at ECS Tuning | ||||||
| 06 | Holder | 1 | 66209306408 | Shop at ECS Tuning | ||||||
| 07 | Insert | 1 | 66209375565 | Shop at ECS Tuning | ||||||
