Front radar sensor, long range for BMW 7 Series G11 LCI 730d (2022)
This Front radar sensor, long range technical drawing provides a detailed breakdown of the assembly for the 7 Series G11 LCI 730d. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2022.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| i | For vehicles with Driving assistant professional or Active cruise control+Stop&Go function |
S5AUA=Yes S5DFA=Yes |
||||||||
| 01 | Front radar sensor, long range | FRR-02 | 1 | 07/2023 | 66315A589B4 | ENDED | Shop at ECS Tuning | |||
| 01 | Front radar sensor, long range | FRR-02 | 1 | 66315A81716 | Shop at ECS Tuning | |||||
| 02 | Radome | 1 | 66316877219 | Shop at ECS Tuning | ||||||
| 03 | Mount front radar sensor | 1 | 66316889079 | Shop at ECS Tuning | ||||||
| 04 | Combi oval-head machine screw | M6X16-8.8-ZNNI | 2 | 07146999225 | Shop at ECS Tuning | |||||
Notes
- ENDED = the part has been discontinued (no longer available).
