Label for BMW 3 Series E30 M3 (1990)
This Label technical drawing provides a detailed breakdown of the assembly for the 3 Series E30 M3. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1990.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Type plate | MOTORSPORT | 1 | 51142121597 | $11.65 | ENDED | Shop at ECS Tuning | |||
| 02 | Label "battery" | 1 | 51141806553 | ENDED | Shop at ECS Tuning | |||||
| 02 | Label "engine oil" | 1 | 51141822234 | ENDED | Shop at ECS Tuning | |||||
| 02 | Label "original BMW teile" | DE/EN/FR/IT | 1 | 51142121173 | $0.68 | Shop at ECS Tuning | ||||
| 02 | Label "run-in instruction" | 1 | 51142121181 | $2.07 | Shop at ECS Tuning | |||||
| 03 | Label "transistorized ignition" | 1 | 71212122014 | $1.27 | Shop at ECS Tuning | |||||
| 04 | Blind rivet | 3,2 2A | 2 | 07129948747 | $0.09 | Shop at ECS Tuning | ||||
| 06 | Label five speed gearbox (Sport) | 1 | 51142121134 | ENDED | Shop at ECS Tuning | |||||
| For vehicles with without catalytic converter |
S199A=No |
|||||||||
| 07 | Label "unleaded fuel" | 1 | 51142121497 | $2.53 | ENDED | Shop at ECS Tuning | ||||
| 07 | Label "unleaded only" | DEUTSCH | 1 | 51142121638 | $2.07 | Shop at ECS Tuning | ||||
| 07 | Label "unleaded only" | (ITALIANO) | 1 | 51142121639 | ENDED | Shop at ECS Tuning | ||||
| 07 | Label "unleaded only" | (ESPANOL) | 1 | 51142121640 | ENDED | Shop at ECS Tuning | ||||
| 07 | Label "unleaded only" | (FRANCAIS) | 1 | 51142121641 | ENDED | Shop at ECS Tuning | ||||
Notes
- ENDED = the part has been discontinued (no longer available).
