Label for BMW 3 Series E30 320i (1992)
This Label technical drawing provides a detailed breakdown of the assembly for the 3 Series E30 320i. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1992.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| For vehicles with National version japan |
L807A=Yes |
|||||||||
| 02 | Label "Brake fluid" | 1 | 51141117340 | ENDED | Shop at ECS Tuning | |||||
| 02 | Label "battery" | 1 | 51141873247 | $8.03 | ENDED | Shop at ECS Tuning | ||||
| 02 | Label "run-in instruction" | 1 | 51142121181 | $2.07 | Shop at ECS Tuning | |||||
| 03 | Label "transistorized ignition" | 1 | 71212122014 | $1.27 | Shop at ECS Tuning | |||||
| 04 | Label "gear shift pattern" | 1 | 51141811705 | $2.92 | Shop at ECS Tuning | |||||
| 05 | Label five speed (overdrive) gearbox | 1 | 51142121028 | $3.71 | ENDED | Shop at ECS Tuning | ||||
| 06 | Label "unleaded fuel" | ENGLISH | 1 | 51142121684 | $2.00 | ENDED | Shop at ECS Tuning | |||
| 07 | Blind rivet | 3,2 2A | 2 | 07129948747 | $0.09 | Shop at ECS Tuning | ||||
Notes
- ENDED = the part has been discontinued (no longer available).
