Single parts, teleph.antenna multi-band for BMW 3 Series E46 325i (2003)

This Single parts, teleph.antenna multi-band technical drawing provides a detailed breakdown of the assembly for the 3 Series E46 325i. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2003.

Single parts, teleph.antenna multi-band
No. Description Supp. Qty  From   Up To  Part Number Price Notes
For vehicles with
Car phone with cordless receiver
or
Preparation BMW Handy (Motorola)
or
Preparation, mobile phone, Business
or
Car telephone Professional
or
Preparation f tel.installation universal
or
Prep. mobile phone USA Universal
or
Preparation f mobile phone w Bluetooth
S630A=Yes

S632A=Yes

S633A=Yes

S638A=Yes

S640A=Yes

S641A=Yes

S644A=Yes
01 Multiband telephone antenna primed 1 09/2001 84500146776 $108.52 ENDED Shop at ECS Tuning
01 Multiband telephone antenna painted CODE-UNI/MET. 1 09/2001 84500153420 $249.00 ENDED Shop at ECS Tuning
02 Gasket, telephone antenna multi-band 1 09/2001 84500146775 $7.12 Shop at ECS Tuning
03 Adhesive tape, double-sided 1 84508021110 $7.12 Shop at ECS Tuning
Notes
  • ENDED = the part has been discontinued (no longer available).
