Single parts, SA 630, trunk for BMW 7 Series E38 735i (2001)

This Single parts, SA 630, trunk technical drawing provides a detailed breakdown of the assembly for the 7 Series E38 735i. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2001.

Single parts, SA 630, trunk
No. Description Supp. Qty  From   Up To  Part Number Price Notes
01 Car telephone connection cable SIEMENS BIT II 1 61126907751 ENDED Shop at ECS Tuning
For vehicles with
Voice control
S620A=Yes
01 Car telephone connection cable SIEMENS BIT II 1 61126907752 ENDED Shop at ECS Tuning
For vehicles with
Second receiver in the rear, cordless
S631A=Yes
01 Car telephone connection cable SIEMENS BIT II 1 61126908854 ENDED Shop at ECS Tuning
For vehicles with
On-board monitor with TV
or
Navigation system Professional
S602A=Yes

S609A=Yes
01 Car telephone connection cable SIEMENS BIT II 1 61126907886 ENDED Shop at ECS Tuning
For vehicles with
Voice control
or
Second receiver in the rear, cordless
S620A=Yes

S631A=Yes
01 Car telephone connection cable SIEMENS BIT II 1 61126908855 ENDED Shop at ECS Tuning
For vehicles with
On-board monitor with TV
and
Navigation system Professional
and
Second receiver in the rear, cordless
S602A=Yes

S609A=No

S631A=Yes
01 Car telephone connection cable SIEMENS BIT II 1 61126908856 ENDED Shop at ECS Tuning
For vehicles with
On-board monitor with TV
and
Navigation system Professional
and
Second receiver in the rear, cordless
S602A=No

S609A=Yes

S631A=Yes
01 Car telephone connection cable SIEMENS BIT II 1 61126908856 ENDED Shop at ECS Tuning
For vehicles with
On-board monitor with TV
and
Navigation system Professional
and
Voice control
S602A=Yes

S609A=No

S620A=Yes
01 Car telephone connection cable SIEMENS BIT II 1 61126907887 ENDED Shop at ECS Tuning
For vehicles with
On-board monitor with TV
and
Navigation system Professional
and
Voice control
S602A=No

S609A=Yes

S620A=Yes
01 Car telephone connection cable SIEMENS BIT II 1 61126907887 ENDED Shop at ECS Tuning
For vehicles with
On-board monitor with TV
and
Navigation system Professional
and
Voice control
and
Second receiver in the rear, cordless
S602A=Yes

S609A=No

S620A=Yes

S631A=Yes
01 Car telephone connection cable SIEMENS BIT II 1 61126908857 ENDED Shop at ECS Tuning
For vehicles with
On-board monitor with TV
and
Navigation system Professional
and
Voice control
and
Second receiver in the rear, cordless
S602A=No

S609A=Yes

S620A=Yes

S631A=Yes
01 Car telephone connection cable SIEMENS BIT II 1 61126908857 ENDED Shop at ECS Tuning
02 Antenna cable, basis antenna SIEMENS BIT II 1 61126907953 ENDED Shop at ECS Tuning
03 Transmitter-receiver SIEMENS BIT II 1 12/2001 84116916766 ENDED Shop at ECS Tuning
03 Transmitter and receiver unit/handset SIEMENS BIT II 1 12/2001 84116924824 ENDED Shop at ECS Tuning
03 Transmitter-receiver SIEMENS BIT II 1 12/2001 84116924823 Shop at ECS Tuning
only in conjunction with
-- Handset SIEMENS BIT II 1 12/2001 84116920275 ENDED Shop at ECS Tuning
04 Bracket transmitter-receiver SIEMENS BIT II 1 84136904929 $6.28 Shop at ECS Tuning
05 Hex bolt M5X14 6 07119902932 $0.53 Shop at ECS Tuning
06 Body nut M5 6 61131372033 $1.37 Shop at ECS Tuning
07 Blind rivet nut, flat headed M5 2 61136954561 $0.63 Shop at ECS Tuning
08 Antenna BLUETOOTH 1 84506928461 $24.30 +core Shop at ECS Tuning
09 Plastic nut for coarse threaded pin M6 2 16131176747 $0.53 Shop at ECS Tuning
10 Rep. kit for socket housing 54 POL. 1 61132471244 Shop at ECS Tuning
only in conjunction with
-- Socket housing 37-54POL. 1 61136909070 $1.08 Shop at ECS Tuning
-- Socket housing 36 POL. 1 61136920062 $1.22 Shop at ECS Tuning
-- Socket terminal MQS 0.2-0.5MM²/SN 54 61138369696 $0.28 Shop at ECS Tuning
-- Socket terminal MQS 0.75 MM² /SN 54 61138369700 $0.35 Shop at ECS Tuning
Notes
  • ENDED = the part has been discontinued (no longer available).
  • +core = plus core charge (possibility of a return of the old part)
