Single parts, SA 638, trunk for BMW 3 Series E46 325i (2005)

This Single parts, SA 638, trunk technical drawing provides a detailed breakdown of the assembly for the 3 Series E46 325i. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2005.

Single parts, SA 638, trunk
No. Description Supp. Qty  From   Up To  Part Number Price Notes
01 Telematics control unit GSM 1 84106978533 ENDED Shop at ECS Tuning
Observe PUMA Measure 53476121
01 RP REMAN Telematic Control Unit GSM 1 84109187926 Shop at ECS Tuning
For vehicles with
Navigation system Professional
or
CD changer for 6 CDs
or
Hi-Fi System Harman Kardon
or
HiFi speaker system
or
Preparation, BMW 6-CD changer I-bus
S609A=Yes

S672A=Yes

S674A=Yes

S676A=Yes

S692A=Yes
02 Bracket for telematics control module 1 84136924551 $7.91 ENDED Shop at ECS Tuning
03 Hex nut with plate M5 4 63259128043 $0.72 Shop at ECS Tuning
04 Hex bolt M5X14 4 07119902932 $0.53 Shop at ECS Tuning
05 Body nut M5 4 61131372033 $1.37 Shop at ECS Tuning
06 Bracket for telematics control module 1 84136924550 $12.99 ENDED Shop at ECS Tuning
07 Bracket f basis antenna 1 84136912160 $3.86 Shop at ECS Tuning
08 Antenna BLUETOOTH 1 84506928461 $24.30 +core Shop at ECS Tuning
Notes
  • ENDED = the part has been discontinued (no longer available).
  • +core = plus core charge (possibility of a return of the old part)
