Single parts, SA 638, trunk for BMW 3 Series E46 325Ci (2006)

This Single parts, SA 638, trunk technical drawing provides a detailed breakdown of the assembly for the 3 Series E46 325Ci. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2006.

Single parts, SA 638, trunk
No. Description Supp. Qty  From   Up To  Part Number Price Notes
01 Telematics control unit GSM 1 84106978533 ENDED Shop at ECS Tuning
Observe PUMA Measure 53476121
01 RP REMAN Telematic Control Unit GSM 1 84109187926 Shop at ECS Tuning
02 Bracket for telematics control module 1 84136924948 $9.80 Shop at ECS Tuning
03 Hex bolt M5X14 5 07119902932 $0.53 Shop at ECS Tuning
04 Body nut M5 5 61131372033 $1.37 Shop at ECS Tuning
For vehicles with
TV function
or
On-board monitor with TV
S601A=Yes

S602A=Yes
05 Bracket for telematics control module 1 84136924688 Shop at ECS Tuning
06 Hex nut with plate M5 4 63259128043 $0.72 Shop at ECS Tuning
07 Bracket f basis antenna 1 84136912160 $3.86 Shop at ECS Tuning
08 Antenna BLUETOOTH 1 84506928461 $24.30 +core Shop at ECS Tuning
Notes
  • ENDED = the part has been discontinued (no longer available).
  • +core = plus core charge (possibility of a return of the old part)
