Single parts Apollo centre console for BMW 7 Series E38 740i (1998)

This Single parts Apollo centre console technical drawing provides a detailed breakdown of the assembly for the 7 Series E38 740i. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1998.

Single parts Apollo centre console
No. Description Supp. Qty  From   Up To  Part Number Price Notes
01 Receiver with keyboard, net GSM MOTOROLA 1 84110139225 ENDED Shop at ECS Tuning
03 Eject box, receiver, net GSM APOLLO 1 84110140352 ENDED Shop at ECS Tuning
For vehicles with
Preparation f tel.installation universal
and
Retrofit, car telephone Apollo
S640A=No

=Yes
04 Cable adapter Interface APOLLO 1 84120030588 $29.30 ENDED Shop at ECS Tuning
05 Interface APOLLO 1 84210151435 ENDED Shop at ECS Tuning
06 SIM card holder APOLLO 1 84110143407 ENDED Shop at ECS Tuning
Notes
  • ENDED = the part has been discontinued (no longer available).
