Individual wood storing partition for BMW 3 Series E36 325td (1998)
This Individual wood storing partition technical drawing provides a detailed breakdown of the assembly for the 3 Series E36 325td. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1998.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| i | Standard wood see Image Text Unit STORING PARTITION --------------------------- Option 438 = Burr walnut 91 Option 738 = Yew Club Option 739 = Birch anthracite Option 773 = Burr walnut 93 Option 773 = Burr walnut E39 for E36/5 Option 490 = Special individual option --------------------------- Bird's-eye maple: beige 0110 / gray 0120 /graphite 0130 --------------------------- |
|||||||||
| ONLY APPLIES TO RETROFITTING ONLY APPLIES TO WOODEN EQUIPMENT/SA438 |
||||||||||
| 01 | Storing partition wood strips | NUSSBAUM-WUR.91 | 1 | 82259402669 | ENDED, +core | Shop at ECS Tuning | ||||
| For vehicles with Wooden trim SA 773 Standard wood |
=Yes |
|||||||||
| 01 | Storing partition cover | NUSSBAUM-WURZEL | 1 | 51162261099 | $667.35 | ENDED, +core | Shop at ECS Tuning | |||
| For vehicles with Left-hand-drive car Individual wood |
=Yes |
|||||||||
| 01 | Storing partition cover | CLASSIC NUßBAUM | 1 | 51162256423 | ENDED, +core | Shop at ECS Tuning | ||||
| 01 | Storing partition cover | PLATANE | 1 | 51162261185 | ENDED, +core | Shop at ECS Tuning | ||||
| 01 | Storing partition cover | BEIGE 0110 | 1 | 51162261186 | ENDED, +core | Shop at ECS Tuning | ||||
| 01 | Storing partition cover | GRAU 0120 | 1 | 51162261187 | ENDED, +core | Shop at ECS Tuning | ||||
| 01 | Storing partition cover | GRAPHIT 0130 | 1 | 51162261188 | ENDED, +core | Shop at ECS Tuning | ||||
| 01 | Storing partition cover | PAPPEL NATUR | 1 | 51162261218 | ENDED, +core | Shop at ECS Tuning | ||||
| 01 | Storing partition cover | EIBE CLUB | 1 | 51162261228 | $686.34 | ENDED | Shop at ECS Tuning | |||
| 01 | Birchwood storing partition cover | ANTHRAZIT 0690 | 1 | 51162423551 | ENDED, +core | Shop at ECS Tuning | ||||
| 01 | Birchwood storing partition cover | ROT 0630 | 1 | 51162423700 | ENDED, +core | Shop at ECS Tuning | ||||
| 01 | Birchwood storing partition cover | GELB 0610 | 1 | 51162423781 | ENDED, +core | Shop at ECS Tuning | ||||
| 01 | Birchwood storing partition cover | BLAU 0650 | 1 | 51162424268 | ENDED, +core | Shop at ECS Tuning | ||||
| 01 | Storing partition cover | BRUYERE | 1 | 51162493339 | ENDED, +core | Shop at ECS Tuning | ||||
| ONLY APPLIES TO RETROFITTING ONLY APPLIES TO WOODEN EQUIPMENT/SA438 |
||||||||||
| 02 | Storing partition wood strips | NUSSBAUM-WUR.91 | 1 | 82259402670 | ENDED | Shop at ECS Tuning | ||||
| For vehicles with Wooden trim SA 773 Standard wood |
=Yes |
|||||||||
| 02 | Storing partition cover | NUSSBAUM-WURZEL | 1 | 51162261103 | $790.60 | ENDED | Shop at ECS Tuning | |||
| For vehicles with Left-hand-drive car Individual wood |
=Yes |
|||||||||
| 02 | Storing partition cover | CLASSIC NUßBAUM | 1 | 51162256424 | ENDED, +core | Shop at ECS Tuning | ||||
| 02 | Storing partition cover | PLATANE | 1 | 51162261180 | ENDED, +core | Shop at ECS Tuning | ||||
| 02 | Storing partition cover | BEIGE 0110 | 1 | 51162261181 | ENDED, +core | Shop at ECS Tuning | ||||
| 02 | Storing partition cover | GRAU 0120 | 1 | 51162261182 | ENDED, +core | Shop at ECS Tuning | ||||
| 02 | Storing partition cover | GRAPHIT 0130 | 1 | 51162261183 | $664.02 | ENDED, +core | Shop at ECS Tuning | |||
| 02 | Storing partition cover | PAPPEL NATUR | 1 | 51162261217 | ENDED, +core, NoS | Shop at ECS Tuning | ||||
| 02 | Storing partition cover | EIBE CLUB | 1 | 51162261227 | $686.34 | ENDED | Shop at ECS Tuning | |||
| 02 | Birchwood storing partition cover | ANTHRAZIT 0690 | 1 | 51162423552 | ENDED, +core | Shop at ECS Tuning | ||||
| 02 | Birchwood storing partition cover | ROT 0630 | 1 | 51162423701 | ENDED, +core | Shop at ECS Tuning | ||||
| 02 | Birchwood storing partition cover | GELB 0610 | 1 | 51162423782 | ENDED, +core | Shop at ECS Tuning | ||||
| 02 | Birchwood storing partition cover | BLAU 0650 | 1 | 51162424269 | ENDED, +core | Shop at ECS Tuning | ||||
| 02 | Storing partition cover | BRUYERE | 1 | 51162493341 | ENDED, +core | Shop at ECS Tuning | ||||
| ONLY APPLIES TO RETROFITTING ONLY APPLIES TO WOODEN EQUIPMENT/SA438 |
||||||||||
| 04 | Storing partition wood strips | NUSSBAUM-WUR.91 | 1 | 82259402672 | ENDED | Shop at ECS Tuning | ||||
| For vehicles with Wooden trim SA 773 Standard wood |
=Yes |
|||||||||
| 04 | Storing partition cover | NUSSBAUM-WU.93 | 1 | 51162261105 | $790.60 | ENDED | Shop at ECS Tuning | |||
| For vehicles with Left-hand-drive car Individual wood |
=Yes |
|||||||||
| 04 | Storing partition cover | CLASSIC NUßBAUM | 1 | 51162256426 | $892.80 | ENDED, +core, NoS | Shop at ECS Tuning | |||
| 04 | Storing partition cover | PLATANE | 1 | 51162261244 | $686.34 | ENDED, +core | Shop at ECS Tuning | |||
| 04 | Storing partition cover | BEIGE 0110 | 1 | 51162261245 | $686.34 | ENDED, +core | Shop at ECS Tuning | |||
| 04 | Storing partition cover | GRAU 0120 | 1 | 51162261246 | $686.34 | ENDED, +core | Shop at ECS Tuning | |||
| 04 | Storing partition cover | GRAPHIT 0130 | 1 | 51162261247 | $686.34 | ENDED, +core | Shop at ECS Tuning | |||
| 04 | Storing partition cover | PAPPEL NATUR | 1 | 51162261290 | $650.07 | ENDED | Shop at ECS Tuning | |||
| 04 | Storing partition cover | EIBE CLUB | 1 | 51162261305 | $650.07 | ENDED | Shop at ECS Tuning | |||
| 04 | Birchwood storing partition cover | ANTHRAZIT 0690 | 1 | 51162423554 | $837.00 | Shop at ECS Tuning | ||||
| 04 | Birchwood storing partition cover | ROT 0630 | 1 | 51162423703 | $837.00 | ENDED, +core | Shop at ECS Tuning | |||
| 04 | Birchwood storing partition cover | GELB 0610 | 1 | 51162423784 | $837.00 | ENDED, +core | Shop at ECS Tuning | |||
| 04 | Birchwood storing partition cover | BLAU 0650 | 1 | 51162424271 | $892.80 | ENDED | Shop at ECS Tuning | |||
| 04 | Storing partition cover | BRUYERE | 1 | 51162493343 | $892.80 | ENDED, +core | Shop at ECS Tuning | |||
Notes
- ENDED = the part has been discontinued (no longer available).
- +core = plus core charge (possibility of a return of the old part)
- NoS = No Stock (Part centrally not stocked)
