K569 (K 75, K 75 C, K 75 S, K 75 RT) K 75 RT (0565,0573) Electrically adjustable windshield

Electrically adjustable windshield
No. Description Supp. Qty  From   Up To  Part Number Price Notes
01 Windshield 6MM 2 46632307474 $469.86 +core
only in conjunction with
-- Cover 6MM 1 46632307537 $4.28
For vehicles with
Official vehicles

=Yes
01 Windshield 1 46632309174 ENDED, +core
For vehicles with
grundiert f.Ersatzteile-Motorrad

U500=Yes
02 Carrier SCHWARZ 1 46632309178 $721.67 ENDED, +core
03 Screw M5X20 4 46632307427 $0.87 ENDED
03 Fillister head screw M5X20 4 46637651349 $1.58
04 Cover 6MM 2 46632307537 $4.28
04 Cover 5MM 2 46632307538 $4.28
05 Pad 4 46632307412 $3.49
06 Pad lower 2 46632307481 $7.21 ENDED
07 Sheet metal screw ST 4,2X19 8 46632309201 $2.39
08 Body nut 6 46632309217 $0.81 ENDED
08 Sheet metal nut, self-locking 6 07147153456 $0.36
09 Label 1 46632307475 $2.48 ENDED
Notes
  • +core = plus core charge (possibility of a return of the old part)
  • ENDED = the part has been discontinued (no longer available).
