K52 (R 1200 RT, R 1250 RT) R 1250 RT 19 (0J61, 0J63) Casing upper part/Headlight

Casing upper part/Headlight
No. Description Supp. Qty  From   Up To  Part Number Price Notes
01 Headlight housing, primed, left 1 46638533559
01 Headlight housing, left ROHTEIL / BLANK 1 46638533571
01 Headlight housing, primed, right 1 46638533560
01 Headlight housing, right ROHTEIL / BLANK 1 46638533572
02 Wind deflector, left 1 46637728781
02 Wind deflector, right 1 46637728782
03 Trim upper section, left 1 46637728815
03 Trim upper section, right 1 46637728816
04 Left loudspeaker cover 1 46638529411
04 Right loudspeaker cover 1 46638529412
05 Front fairing, inner left 1 46638520289
05 Front fairing, inner right 1 46638520290
06 Body screw with shoulder M5X14,5-A2-70 16 46638521653
07 Bump stop H=5,5MM 2 46632309923 $2.80
08 Body screw with shoulder M5X17,5-A2-70 4 46638521654
09 C-clip nut, self-locking M5 16 46638532314
10 Grommet 2 46638532168
11 Plastic washer M5X12,5X0,5 X 46638521659
