K52 (R 1200 RT, R 1250 RT) R 1250 RT 19 (0J61, 0J63) Mounting parts of radio telephone box

Mounting parts of radio telephone box
No. Description Supp. Qty  From   Up To  Part Number Price Notes
  i For vehicles with
Single seat with 2-way radio module

X642A=Yes
01 Radio com box, top section, primed 1 46637693160
01 Upper part of radio telephone box ROHTEIL / BLANK 1 46637693159
02 Backrest in imitation leather, black 1 46637694556 $123.54 +core
03 Flat nut M5 2 46637707388
04 Fillister head screw TS 5X16 2 51417067920 $0.39
05 Body screw without shoulder M5X14-A2-70 7 46638534938
06 C-clip nut, self-locking M5 7 46638532314
07 Badge D=45MM 1 31427708518 $19.85
Notes
  • +core = plus core charge (possibility of a return of the old part)
