2500-3.3Li 2500 Door window lifting mechanism rear

Door window lifting mechanism rear
No. Description Supp. Qty  From   Up To  Part Number Price Notes
01 Hex bolt M6X12 4 07119913442 $0.25 ENDED
01 Hex bolt M6X12-8.8-ZNNIV 4 07119905524 $0.27
02 Tooth washer A6,4 4 07119936133 $0.38
03 Washer 6,4 4 02/1977 07119936425 $0.09 ENDED
03 Washer A6,4-200HV-ZNS3 4 07119903791 $0.11
04 Fillister head self-tapping screw ST2,9X13 2 07119906706 $0.09 ENDED
05 Set recess.oval head sheet-metal screw20 ST2,9X13 4 07509063305 ENDED
06 Set fillister head self-tapping screw 20 ST4,2X13 2 07509064383 ENDED
07 Fillister head self-tapping screw ST4,8X9,5 2 02/1977 07119906762 $0.12 ENDED
07 Sheet metal screw ST4,8X9,5-C-H-Z 2 07119901200 $0.17
08 Washer 6,4 2 02/1977 07119931044 $0.58 ENDED
08 Washer A6,4-ZNS 2 02/1977 07119931018 $0.40 ENDED
08 Washer A6,4-ZNNIV SI 2 07119904202
09 Cable clip B2 2 07119977615 ENDED
Notes
  • ENDED = the part has been discontinued (no longer available).
