7' E32 750i Hood parts, rear door
Sponsored links
Sponsored links
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | |
|---|---|---|---|---|---|---|---|---|---|
| 01 | Trunk lid | 1 | 86290008768 | ENDED | |||||
| 02 | BMW emblem | 1 | 51148123297 | $28.78 | |||||
| 02 | Label | 1 | 86199416544 | $11.00 | ENDED | ||||
| 03 | Rear door cover | 135X76MM | 1 | 86290008769 | ENDED | ||||
| 04 | Label | 1 | 86290008770 | ENDED | |||||
| 05 | Fillister head self-tapping screw | ST3,5X8 | 4 | 07119900281 | $0.36 | ||||
| 06 | Adjustment angle | 2 | 86290008771 | ENDED | |||||
| 07 | Hinge left | 1 | 86290008772 | ENDED | |||||
| 08 | Hinge right | 1 | 86290008773 | ENDED | |||||
| 09 | Bracket | 2 | 86290008774 | ENDED | |||||
| 10 | Hex bolt | M8X20 | X | 07/1990 | 07119913644 | $0.20 | ENDED | ||
| 10 | Hex bolt | M8X20-ZNS | X | 07119901120 | $0.60 | ENDED | |||
| 10 | Hex bolt | M8X20-ZNNIV SI | X | 07119903039 | |||||
| 11 | Washer | A8,4-ZNS | X | 07119931019 | $0.40 | ||||
| 12 | Gas pressurized spring | 400 N | 2 | 86290008775 | $34.75 | ENDED | |||
| 13 | Hex nut | M8-04-2-ZNS | 4 | 04/1994 | 07119921104 | $0.56 | ENDED | ||
| 13 | Hex nut | M8-05-ZNNIV SI | 4 | 07119904948 | $1.00 | ||||
| 14 | Clamp | 2 | 86190002059 | $0.75 | ENDED |
Notes
- ENDED = the part has been discontinued (no longer available).
