X5 M F85 X5 M Various body parts

Various body parts
No. Description Supp. Qty  From   Up To  Part Number Price Notes
01 Left engine compartm.protection bracket 1 51717188835 $18.57
01 Right engine compartm.protection bracket 1 51717188836 $18.57
02 Plastic capnut with washer D=18MM 4 51161943122 $0.39
03 Hex head screw ST4,8X19-U2 SW 2 07119904288 $2.05
05 Hex nut M6 2 07146988146 $0.47
06 Hex bolt with washer M6X18-U1 2 07119905399 $0.36
07 Bracket for accelerator pedal module 1 41127137686
08 Reinforcement, pedal assembly 1 51717137332 +core
09 Hex bolt with washer M6X12.4MM ZNS3 6 07146954299 $0.64
09 Hex bolt with washer M6X14U2-ZNNIVSI 6 07119905952 $0.91
10 Hex nut BM6-8-ZNNIV SI 2 07129905411 $0.38
12 cover, floor panel rear 2 51717124999 $4.70
13 seal, cap 2 51718227359 $1.15
14 Hex nut M6-8-ZNFE SW 8 07119904022 $0.09
Notes
  • +core = plus core charge (possibility of a return of the old part)
