Techo corredizo levadizo,piezas sueltas for BMW 7 Series G12 740LiX (2018)
This Techo corredizo levadizo,piezas sueltas technical drawing provides a detailed breakdown of the assembly for the 7 Series G12 740LiX. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2018.
| No. | Descripción | suplemento | Cantidad | Desde | Hasta | Número de pieza | Precio | Notas | ||
|---|---|---|---|---|---|---|---|---|---|---|
| i | Para vehículos con Techo de cristal, eléctrico |
S403A=Sí |
||||||||
| 01 | Accionamiento techo corredizo | 2 | 67617316536 | Shop at ECS Tuning | ||||||
| solo en combinacion con | ||||||||||
| -- | Tornillo cabeza cil. | M5X28 | 3 | 54107209205 | $1.98 | Shop at ECS Tuning | ||||
| 02 | Mecánica del techo corredizo | 1 | 54107209198 | $169.62 | Shop at ECS Tuning | |||||
| solo en combinacion con | ||||||||||
| -- | Juego tiras de fieltro autoadhesivas | 1 | 51452353024 | Shop at ECS Tuning | ||||||
| 03 | Juego de reparacion techo corredizo | 2 | 54107209196 | $22.15 | Shop at ECS Tuning | |||||
| solo en combinacion con | ||||||||||
| -- | Juego tiras de fieltro autoadhesivas | 1 | 51452353024 | Shop at ECS Tuning | ||||||
| 04 | Canaleta vierteaguas | 1 | 54107209281 | Shop at ECS Tuning | ||||||
| 05 | Junta canaleta vierteaguas | 1 | 54107209197 | Shop at ECS Tuning | ||||||
| 06 | Parabrisas | 1 | 54107382984 | Shop at ECS Tuning | ||||||
| 07 | Panel protector protección visual | 2 | 54107382987 | Shop at ECS Tuning | ||||||
| 08 | Fuelle | 2 | 54107181951 | $18.05 | Shop at ECS Tuning | |||||
| 09 | Inter.d.emerg.crist.elect.3tech.cor.ele. | 1 | 54127199322 | $9.78 | Shop at ECS Tuning | |||||
| 10 | Tornillo cabeza cil. | M5X28 | 6 | 54107209205 | $1.98 | Shop at ECS Tuning | ||||
