Pieces de projecteur xenon a regl. auto for BMW 5 Series E39 525td (1998)
This Pieces de projecteur xenon a regl. auto technical drawing provides a detailed breakdown of the assembly for the 5 Series E39 525td. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1998.
| N° | Descriptions | Supplément | Qté | A partir de | Jusqu'à | Référence pièce | Prix | Note | ||
|---|---|---|---|---|---|---|---|---|---|---|
| i | convient uniquement pour kit de postéquipement 63 12 0 009 949 Attention : La notice de montage ne fait pas partie du kit de postéquipement. Imprimer la notice actualisée sur le portail Aftersales Assistance Portal (ASAP) et la remettre au client. |
|||||||||
| 01 | Adaptateur, lumière xénon | AUTOMAT. LWR | 2 | 63120010309 | $168.95 | arrêté | Shop at ECS Tuning | |||
| 02 | Capteur de niveau | AUTOMAT. LWR | 1 | 63120010307 | $164.95 | arrêté | Shop at ECS Tuning | |||
| 03 | Faisceau de cables lumière Xenon | AUTOMAT. LWR | 1 | 63120010311 | arrêté | Shop at ECS Tuning | ||||
| 04 | Fusible | 500MA | 2 | 63120015957 | arrêté | Shop at ECS Tuning | ||||
Note
- arrêté = la pièce n'est plus produite.
