Remorque module moto for BMW 5 Series E39 525td (1998)
This Remorque module moto technical drawing provides a detailed breakdown of the assembly for the 5 Series E39 525td. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1998.
| N° | Descriptions | Supplément | Qté | A partir de | Jusqu'à | Référence pièce | Prix | Note | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Module moto | 1 | 86229410983 | $261.95 | arrêté | Shop at ECS Tuning | ||||
| 02 | Etrier | 1 | 86299416287 | arrêté, +vieille matière | Shop at ECS Tuning | |||||
| 03 | Kit 2ème monte | 1 | 86299416293 | arrêté, +vieille matière | Shop at ECS Tuning | |||||
| 04 | Boulon d'écartement | 1 | 86299416288 | arrêté | Shop at ECS Tuning | |||||
| 05 | Sangle-tendeur | 4 | 86309416266 | arrêté, +vieille matière | Shop at ECS Tuning | |||||
| 06 | Protection contre frottement | 4 | 86309416267 | arrêté | Shop at ECS Tuning | |||||
| 07 | Boucle d'arrimage | 4 | 86199416290 | $10.75 | arrêté | Shop at ECS Tuning | ||||
| 08 | Rampe de charge | 1 | 86309410984 | $1319.00 | arrêté | Shop at ECS Tuning |
Note
- arrêté = la pièce n'est plus produite.
- +vieille matière = consigne de la vieille matière (possibilité de retourner la vieille pièce)
See Also
Frequently Asked Questions
- What assembly is shown in the BMW 5 Series E39 525td Remorque module moto?
- This technical diagram illustrates the Remorque module moto within the Post-équipement/transformation/access. group for the 5 Series E39 525td produced during 1998. It provides a detailed exploded view of the components, identifying key parts such as the Module moto (Part #86229410983).
- Which models use the hardware listed in this Remorque module moto?
- The hardware and components featured in the Remorque module moto are specific to the 5 Series E39 525td produced during 1998. These technical specifications ensure that parts like the Module moto (86229410983) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the Remorque module moto assembly?
- Each item in the Remorque module moto corresponds to the numbered list below the illustration. For the 5 Series E39 525td, you can identify the Module moto by locating its position on the schematic, which then links to the official BMW part number 86229410983 for the Post-équipement/transformation/access. section.
