Remorque module transport for BMW 5 Series E39 525td (1998)
This Remorque module transport technical drawing provides a detailed breakdown of the assembly for the 5 Series E39 525td. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1998.
| N° | Descriptions | Supplément | Qté | A partir de | Jusqu'à | Référence pièce | Prix | Note | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Module transport 1 | 1 | 86239410985 | $59.50 | arrêté | Shop at ECS Tuning | ||||
| uniquement en combinaison avec | ||||||||||
| -- | Barre alu "Profil 2000" | 1 | 86239415851 | $75.89 | arrêté, +vieille matière | Shop at ECS Tuning | ||||
| 02 | Module transport 2 | 1 | 86239410986 | $89.00 | arrêté | Shop at ECS Tuning | ||||
| uniquement en combinaison avec | ||||||||||
| -- | Barre alu "Profil 2000" | 1 | 86239415851 | $75.89 | arrêté, +vieille matière | Shop at ECS Tuning | ||||
| 03 | Barre alu "Profil 2000" | 1 | 86239415851 | $75.89 | arrêté, +vieille matière | Shop at ECS Tuning | ||||
| 04 | Kit 2ème monte | 1 SATZ | 4 | 86299415495 | arrêté | Shop at ECS Tuning | ||||
| 05 | Clé à six pans creux | SW8 | 1 | 71111237849 | $3.34 | Shop at ECS Tuning | ||||
| 05 | Clé à six pans creux | SW6 | 1 | 71111237850 | $2.16 | Shop at ECS Tuning | ||||
| 06 | Capuchon | 4 | 82719402947 | $1.50 | arrêté | Shop at ECS Tuning | ||||
| 07 | Recouvrement superieur | 2 | 82129413122 | $7.50 | arrêté | Shop at ECS Tuning | ||||
| 08 | Collier de serrage avec vis (code) | 4 | 82790004335 | $41.50 | arrêté, +vieille matière | Shop at ECS Tuning | ||||
| 09 | Jeu de clés avec vis | 1 | 82799405049 | $29.00 | arrêté | Shop at ECS Tuning | ||||
| 10 | Clé (Code) | 1 | 82799405012 | $11.75 | arrêté | Shop at ECS Tuning | ||||
Note
- arrêté = la pièce n'est plus produite.
- +vieille matière = consigne de la vieille matière (possibilité de retourner la vieille pièce)
