Soupapes/conduite de dispositif d'inject for BMW 2500-3.3Li 3.0Si
This Soupapes/conduite de dispositif d'inject technical drawing provides a detailed breakdown of the assembly for the 2500-3.3Li 3.0Si. It includes part names, part numbers and all associated mounting hardware.
| N° | Descriptions | Supplément | Qté | A partir de | Jusqu'à | Référence pièce | Prix | Note | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Relais de démarreur | 1 | 61311352156 | $39.55 | arrêté | Shop at ECS Tuning | ||||
| 02 | Vis | 3 | 07119904170 | $0.17 | Shop at ECS Tuning | |||||
| 03 | Relais pour depart a froid | 1 | 61311354858 | $99.58 | arrêté | Shop at ECS Tuning | ||||
| 04 | Ecrou tôlé | ST4,2-1-ZNS3 | 3 | 07129904220 | $0.09 | Shop at ECS Tuning | ||||
| 05 | Tuyau de carburant | 8X13MM | 1 | 16121180409 | $20.43 | Shop at ECS Tuning | ||||
| 06 | Palpeur de pression | 1 | 13631360678 | $1046.93 | arrêté | Shop at ECS Tuning | ||||
| 10 | Sonde de température de l'air aspiré | 1 | 13621353331 | $84.44 | arrêté | Shop at ECS Tuning | ||||
| 11 | Anneau d'étanchéité | A8X11,5-AL | 1 | 07119963041 | $0.57 | Shop at ECS Tuning | ||||
| 12 | Vis six pans | M6X12-8.8-ZNNIV | 4 | 07119905524 | $0.27 | Shop at ECS Tuning | ||||
| 13 | Plaque d'appui | A6,4-ZNNIV SI | 2 | 07119904202 | Shop at ECS Tuning | |||||
| 14 | Support | 1 | 09/1971 | 02/1977 | 13631353332 | arrêté | Shop at ECS Tuning | |||
| 15 | Ecrou à six pans | M6-8-ZNNIV SI | 2 | 07119905543 | $0.38 | Shop at ECS Tuning | ||||
| 16 | Rondelle elastique | B6 | 4 | 07119932072 | $0.09 | arrêté | Shop at ECS Tuning |
Note
- arrêté = la pièce n'est plus produite.
