Soupapes/conduite de dispositif d'inject for BMW 2500-3.3Li 3.0Si
This Soupapes/conduite de dispositif d'inject technical drawing provides a detailed breakdown of the assembly for the 2500-3.3Li 3.0Si. It includes part names, part numbers and all associated mounting hardware.
| N° | Descriptions | Supplément | Qté | A partir de | Jusqu'à | Référence pièce | Prix | Note | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Vis à tôle | ST4,8X9,5-C-H-Z | 6 | 07119901200 | $0.17 | Shop at ECS Tuning | ||||
| 02 | Rondelle elastique | B5 | 6 | 07119932098 | $0.38 | Shop at ECS Tuning | ||||
| 03 | Resistance | 1 | 13641358095 | $75.00 | arrêté | Shop at ECS Tuning | ||||
| 04 | Boîtier de connecteur | 1 | 61131355669 | arrêté | Shop at ECS Tuning | |||||
| 05 | Resistance | 1 | 13641357418 | $95.46 | Shop at ECS Tuning | |||||
| 06 | Relais pour depart a froid | 1 | 61311354858 | $99.58 | arrêté | Shop at ECS Tuning | ||||
| 07 | Combinaison relais | 1 | 13631273139 | $125.48 | arrêté | Shop at ECS Tuning | ||||
| 10 | Ecrou à six pans | M6-8-ZNNIV SI | 2 | 07119905543 | $0.38 | Shop at ECS Tuning | ||||
| 11 | Rondelle elastique | B6 | 2 | 09/1973 | 02/1977 | 07119932072 | $0.09 | arrêté | Shop at ECS Tuning | |
| 12 | Plaque d'appui | A6,4-ZNNIV SI | 2 | 09/1973 | 02/1977 | 07119904202 | Shop at ECS Tuning | |||
| 13 | Support | 1 | 09/1973 | 02/1977 | 13631358853 | arrêté | Shop at ECS Tuning |
Note
- arrêté = la pièce n'est plus produite.
