Tuyau de frein avant for BMW 1500-2000CS 1800 (1971)
This Tuyau de frein avant technical drawing provides a detailed breakdown of the assembly for the 1500-2000CS 1800. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1971.
| N° | Descriptions | Supplément | Qté | A partir de | Jusqu'à | Référence pièce | Prix | Note | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Flexible de frein | 2 | 34321159882 | $45.25 | Shop at ECS Tuning | |||||
| 02 | Ressort de fixation | 2 | 34341163565 | $0.97 | Shop at ECS Tuning | |||||
| 04 | Tuyau | M10/M10-1305MM | 1 | 34326755617 | $5.80 | arrêté | Shop at ECS Tuning | |||
| 05 | Manchon caoutchouc | 2 | 34324450359 | arrêté | Shop at ECS Tuning | |||||
| 06 | Manchon de caoutchouc | 2 | 34324050540 | $1.32 | Shop at ECS Tuning | |||||
| 08 | Tuyau | M10/M10-523MM | 1 | 34306779191 | $24.27 | Shop at ECS Tuning |
Note
- arrêté = la pièce n'est plus produite.
See Also
Frequently Asked Questions
- What assembly is shown in the BMW 1500-2000CS 1800 Tuyau de frein avant?
- This technical diagram illustrates the Tuyau de frein avant within the Freins group for the 1500-2000CS 1800 produced during 1971. It provides a detailed exploded view of the components, identifying key parts such as the Flexible de frein (Part #34321159882).
- Which models use the hardware listed in this Tuyau de frein avant?
- The hardware and components featured in the Tuyau de frein avant are specific to the 1500-2000CS 1800 produced during 1971. These technical specifications ensure that parts like the Flexible de frein (34321159882) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the Tuyau de frein avant assembly?
- Each item in the Tuyau de frein avant corresponds to the numbered list below the illustration. For the 1500-2000CS 1800, you can identify the Flexible de frein by locating its position on the schematic, which then links to the official BMW part number 34321159882 for the Freins section.
