Insonorisation for BMW 3 Series E30 325ix (1989)
This Insonorisation technical drawing provides a detailed breakdown of the assembly for the 3 Series E30 325ix. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1989.
| N° | Descriptions | Supplément | Qté | A partir de | Jusqu'à | Référence pièce | Prix | Note | ||
|---|---|---|---|---|---|---|---|---|---|---|
| ne convenant qu'avec capot avant | ||||||||||
| 01 | Jeu insonorisation | 1 | 51481972245 | $79.80 | Shop at ECS Tuning | |||||
| 04 | Materiau anti-bruit du longeron gauche | 1 | 51481911387 | $13.02 | arrêté | Shop at ECS Tuning | ||||
| 04 | Insonorisation traverse droite | 1 | 51481911388 | $13.02 | Shop at ECS Tuning | |||||
| 05 | Materiau anti-bruit du longeron gauche | 1 | 51481911389 | $12.14 | Shop at ECS Tuning | |||||
| 05 | Insonorisation traverse droite | 1 | 51481911390 | $12.14 | Shop at ECS Tuning | |||||
| 06 | Insonorisation boite a gants | 1 | 51481913064 | $3.43 | Shop at ECS Tuning | |||||
| 07 | Materiau anti-bruit plancher de coffre | 1 | 51488100400 | arrêté | Shop at ECS Tuning | |||||
| NE CONVENANT QU'AVEC PNEUS 205/55 | ||||||||||
| 07 | Materiau anti-bruit plancher de coffre | 1 | 51488100428 | arrêté | Shop at ECS Tuning | |||||
Note
- arrêté = la pièce n'est plus produite.
