Insonorisation for BMW 3 Series E30 325ix (1989)
This Insonorisation technical drawing provides a detailed breakdown of the assembly for the 3 Series E30 325ix. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1989.
| N° | Descriptions | Supplément | Qté | A partir de | Jusqu'à | Référence pièce | Prix | Note | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Insonorisation de compartiment moteur g | 1 | 51481962045 | $36.59 | Shop at ECS Tuning | |||||
| 01 | Mater.antibru.hayon ava.compar.moteur c. | 1 | 51481962046 | arrêté | Shop at ECS Tuning | |||||
| 01 | Insonorisation de compartiment moteur D | 1 | 51481962048 | $37.71 | Shop at ECS Tuning | |||||
| 02 | insonorisant tablier habitacle | 1 | 51481906393 | $85.14 | Shop at ECS Tuning | |||||
| 03 | Materiaux antibruit plafond avant | 1 | 51481884260 | $14.06 | Shop at ECS Tuning | |||||
| 04 | Materiau anti-bruit plafond central | 1 | 51481947288 | arrêté | Shop at ECS Tuning | |||||
| 05 | Materiaux antibruit plafond arriere | 1 | 51481947287 | arrêté | Shop at ECS Tuning | |||||
| 06 | Materiau anti-bruit gauche | 1 | 51481947453 | arrêté | Shop at ECS Tuning | |||||
| 06 | Materiau anti-bruit droit | 1 | 51481947454 | arrêté | Shop at ECS Tuning | |||||
| 07 | Materiau anti-bruit gauche | 1 | 51481947451 | arrêté | Shop at ECS Tuning | |||||
| 07 | Materiau anti-bruit droit | 1 | 51481947452 | arrêté | Shop at ECS Tuning | |||||
| 08 | Rivet | X | 51481884779 | $0.57 | Shop at ECS Tuning | |||||
| 09 | Rivet | X | 51481904142 | $0.57 | Shop at ECS Tuning | |||||
| 10 | Insonorisation de passage de roue ar D | 1 | 51481947374 | arrêté | Shop at ECS Tuning | |||||
| 10 | Insonorisation de passage de roue ar g | 1 | 51481947375 | Shop at ECS Tuning | ||||||
| 11 | Bouton-poussoir | D=30MM;H=13MM | X | 51481923999 | $0.42 | Shop at ECS Tuning | ||||
| 12 | Bouton-poussoir | X | 61131373669 | $0.93 | Shop at ECS Tuning | |||||
| 13 | Revêtement antirésonnant | 1160X700MM | 1 | 51488165271 | $50.35 | Shop at ECS Tuning |
Note
- arrêté = la pièce n'est plus produite.
See Also
Frequently Asked Questions
- What assembly is shown in the BMW 3 Series E30 325ix Insonorisation?
- This technical diagram illustrates the Insonorisation within the Equipement véhicule group for the 3 Series E30 325ix produced during 1989. It provides a detailed exploded view of the components, identifying key parts such as the Insonorisation de compartiment moteur g (Part #51481962045).
- Which models use the hardware listed in this Insonorisation?
- The hardware and components featured in the Insonorisation are specific to the 3 Series E30 325ix produced during 1989. These technical specifications ensure that parts like the Insonorisation de compartiment moteur g (51481962045) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the Insonorisation assembly?
- Each item in the Insonorisation corresponds to the numbered list below the illustration. For the 3 Series E30 325ix, you can identify the Insonorisation de compartiment moteur g by locating its position on the schematic, which then links to the official BMW part number 51481962045 for the Equipement véhicule section.
