Revetement de SOL for BMW 3 Series E30 325ix (1989)
This Revetement de SOL technical drawing provides a detailed breakdown of the assembly for the 3 Series E30 325ix. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1989.
| N° | Descriptions | Supplément | Qté | A partir de | Jusqu'à | Référence pièce | Prix | Note | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Revetement de SOL | SCHIEFER | 1 | 51471976635 | $485.46 | arrêté | Shop at ECS Tuning | |||
| 01 | Revetement de SOL | NATUR | 1 | 51471976638 | $484.35 | arrêté | Shop at ECS Tuning | |||
| 02 | Caisson-siege | SCHIEFER | 1 | 51471947323 | $241.06 | arrêté | Shop at ECS Tuning | |||
| 02 | Caisson-siege | NATUR | 1 | 51471947951 | $241.06 | arrêté | Shop at ECS Tuning | |||
| 03 | Revêtement de coffre | SCHIEFER | 1 | 51471947351 | arrêté | Shop at ECS Tuning | ||||
| 03 | Revêtement de coffre | NATUR | 1 | 51471947352 | arrêté | Shop at ECS Tuning | ||||
| 04 | Ecrou à chape | M5 | 3 | 51711934930 | $0.23 | Shop at ECS Tuning |
Note
- arrêté = la pièce n'est plus produite.
