Caméra Ultrasonic Automated Parking for BMW 5 Series G60 Berline 520d (2025)
This Caméra Ultrasonic Automated Parking technical drawing provides a detailed breakdown of the assembly for the 5 Series G60 Berline 520d. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2025.
| N° | Descriptions | Supplément | Qté | A partir de | Jusqu'à | Référence pièce | Prix | Note | ||
|---|---|---|---|---|---|---|---|---|---|---|
| i | Pour véhicules avec Système d'aide au stationnement Plus ou Parking assistant professional ou BMW Personal pilot |
S5DNA=Oui S5DWA=Oui S5DXA=Oui |
||||||||
| Pour véhicules avec Système d'aide au stationnement Plus et Parking assistant professional |
S5DNA=Oui S5DWA=Oui |
|||||||||
| 01 | Caméra Ultrasonic Automated Parking | 4 | 66555A47225 | Shop at ECS Tuning | ||||||
| Pour véhicules avec Système d'aide au stationnement Plus et Parking assistant professional |
S5DNA=Oui S5DWA=Non |
|||||||||
| 01 | Caméra Ultrasonic Automated Parking | 4 | 66555A47225 | Shop at ECS Tuning | ||||||
| Pour véhicules avec Système d'aide au stationnement Plus et Parking assistant professional |
S5DNA=Non S5DWA=Oui |
|||||||||
| 01 | Caméra Ultrasonic Automated Parking | 4 | 66555A47225 | Shop at ECS Tuning | ||||||
| Pour véhicules avec Système d'aide au stationnement Plus et Parking assistant professional |
S5DNA=Oui S5DWA=Oui |
|||||||||
| 02 | Boîtier électr.caméra Automated Parking | 1 | 03/2025 | 66555B60EA8 | Shop at ECS Tuning | |||||
| 02 | Boîtier électr.caméra Automated Parking | 1 | 66555B65A37 | Shop at ECS Tuning | ||||||
| Pour véhicules avec Système d'aide au stationnement Plus et Parking assistant professional |
S5DNA=Oui S5DWA=Non |
|||||||||
| 02 | Boîtier électr.caméra Automated Parking | 1 | 03/2025 | 66555B60EA8 | Shop at ECS Tuning | |||||
| 02 | Boîtier électr.caméra Automated Parking | 1 | 66555B65A37 | Shop at ECS Tuning | ||||||
| Pour véhicules avec Système d'aide au stationnement Plus et Parking assistant professional |
S5DNA=Non S5DWA=Oui |
|||||||||
| 02 | Boîtier électr.caméra Automated Parking | 1 | 03/2025 | 66555B60EA8 | Shop at ECS Tuning | |||||
| 02 | Boîtier électr.caméra Automated Parking | 1 | 66555B65A37 | Shop at ECS Tuning | ||||||
| 03 | Support de boîtier électronique | 1 | 66539505267 | Shop at ECS Tuning | ||||||
| 04 | Ecrou six pans avec plaque | M6-8-ZNNIV SI | 3 | 07119905544 | $0.64 | Shop at ECS Tuning | ||||
| 05 | Ecrou plast. axe à filetage à pas gros | M6 | 2 | 16131176747 | $0.53 | Shop at ECS Tuning | ||||
