Mascherine est./griglia decorativa II for BMW MINI Cabrio F57 JCW (2020)
This Mascherine est./griglia decorativa II technical drawing provides a detailed breakdown of the assembly for the MINI Cabrio F57 JCW. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2020.
| No. | Descrizione | Supplemento | Qtà | Da | Fino a | Codice Ricambio | Prezzo | Note | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Mascherina deflettore d'aria superiore | 1 | 51337356293 | Shop at ECS Tuning | ||||||
| 02 | Guarnizione parabrezza montante A | 1 | 10/2021 | 51337356294 | TERMINATO | Shop at ECS Tuning | ||||
| 02 | Guarnizione parabrezza montante A | 1 | 51335A4C500 | Shop at ECS Tuning | ||||||
| 03 | Mascherina montante A sinistr | 1 | 51137356297 | Shop at ECS Tuning | ||||||
| 03 | Mascherina montante A destra | 1 | 51137356298 | Shop at ECS Tuning | ||||||
| 04 | Guarnizione montante A sinistro | 1 | 51337356295 | Shop at ECS Tuning | ||||||
| 04 | Guarnizione montante A destro | 1 | 51337356296 | Shop at ECS Tuning | ||||||
| 05 | Schermo angolare sinistra | 1 | 51337299987 | Shop at ECS Tuning | ||||||
| 05 | Schermo angolare destra | 1 | 51337299988 | Shop at ECS Tuning | ||||||
| 06 | Vite a testa bombata con rond.di spess. | DELTA PT4X12 | 12 | 07149200941 | Shop at ECS Tuning | |||||
| 07 | Bocchetta | 10 | 07130557302 | $0.21 | Shop at ECS Tuning | |||||
| 07 | Bocchetta | 10 | 51137127001 | $0.85 | Shop at ECS Tuning | |||||
| 08 | Clip rossa | 8 | 07146962771 | $0.28 | Shop at ECS Tuning | |||||
| 09 | Clip con rosetta natur | WEIß | 10 | 51418224768 | $0.69 | Shop at ECS Tuning |
Note
- TERMINATO = Il ricambio è fuori produzione.
