Terzo fanale freno for BMW 5 Series E39 528i (2000)
This Terzo fanale freno technical drawing provides a detailed breakdown of the assembly for the 5 Series E39 528i. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2000.
| No. | Descrizione | Supplemento | Qtà | Da | Fino a | Codice Ricambio | Prezzo | Note | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Terzo fanale freno | 1 | 63258362297 | $231.90 | Shop at ECS Tuning | |||||
| 02 | Cappuccio copertura 3o fanale freno | 1 | 63218371357 | $0.95 | Shop at ECS Tuning | |||||
| 03 | Dado di scartamento | 2 | 63131378066 | $0.23 | Shop at ECS Tuning | |||||
| 04 | Vite, materiali sintetici termoplastici | TS 4X10 | 2 | 07129900239 | $1.05 | Shop at ECS Tuning | ||||
| 05 | Involucro perno univ.senza codice | 3 POL. | 1 | 61136931929 | $2.00 | Shop at ECS Tuning | ||||
| solo in collegamento con | ||||||||||
| -- | Contatto a spina MQS con cavo | 0,2- 0,5QMM | 3 | 61130005198 | $1.82 | Shop at ECS Tuning | ||||
| -- | Contatto a spina MQS con cavo | 0,5-0,75 QMM AG | 3 | 61130070562 | Shop at ECS Tuning | |||||
| -- | Involucro perno univ.senza codice | 3 POL. | 1 | 61136931929 | $2.00 | Shop at ECS Tuning | ||||
